MICRO USB 2.0
Series 801 Mighty Mouse
805-084 and 805-085 Receptacle with USB Micro “AB”
Female Interface to Crimp Removable Contacts
How To Order
Sample Part Number
805-084
805-084
= Shield Termination Porch
805-085
= Accessory Threads
02
= Square Flange Mount Receptacle
07
= Jam Nut Mount Receptacle
-07 MUSB
-M
A
Series 805 Triple Start
Series
Shell Style
Shell Material and Finish
1
Aternate Key Positions
1
Receptacles and
Rear View of Crimp
Termination
NF
= AL/Cadmium, Olive Drab
M
= AL/Electroless Nickel
MT
= AL/Nickel PTFE
ZNU
= AL/Black Zinc Nickel
A, B, C, D, E, F
805-084-02 AND 805-085-02 SQUARE FLANGE,
SHELL SIZE 10
1, 2
4 X Ø.091/.096
(2.31/2.44)
Pin ID 1
Master Keyway
Ø1.330 (33.78)
805-084-07 AND 805-085-07 JAM NUT, SHELL
SIZE 10
1, 2
Mating Face View
Master
Keyway
Pin ID 1
Rear Grommet View
Micro USB “AB” Female Interface
Ø.880 (22.35)
.661 (16.79)
Flat
.850 (21.59)
Flat
1.188 (30.18) Max
.100 (2.54) Max
Panel Thickness
.430
(10.92)
Max
.060
(1.52)
ø.472 (11.99)
ID D+ D-
G
V
J
Front Face View
.785
(19.34) .975
Bsc (24.77)
Sq
ID D+ D-
G
V
Rear Grommet View
1.030 (33.10)
Max
.430 (10.92)
Max
.060 (1.52)
12345
Ø.472 (11.99)
Micro “AB”
female
interface
accepts both
Micro “A”
and Micro
“B” male
interfaces.
.150 (3.81) Max
Red Full Mate
Indicator Band
.6250-.1P-.3L-TS-2B
.150 (3.81)
Max
Red Full Mate
Indicator Band
.6250-.1P-.3L-TS-2B
.5000-28 UNEF-2A
.6875-28 UN-2A
Red Full Mate
Indicator Band
.6250-.1P-.3L-TS-2B
.6875-28 UNEF-2A
Red Full Mate
Indicator Band
.5000-28 UNEF-2A
.6250-.1P-.3L-TS-2B
805-084-02 Receptacle
805-085-02 Receptacle
with Shield Termination Porch with Accessory Threads
805-084-07 Receptacle
805-085-07 Receptacle
with Shield Termination Porch with Accessory Threads
Wire Schematic
Rear Grommet Side
Label Cable Color (Typ)
V
Red
G
Black
D-
White
D+
Green
ID
None
ID
1
2
3
4
5
Mating Side
Micro USB Pin Description
VBUS (V)
D-
D+
ID
GND (G)
NOTES
1. See Section A for recommended panel cutout, additional
finishes and alternate keyway positions.
2. These plug connectors mate with Glenair receptacles 805-082,
805-083, 805-087 and 805-088.
Ground
J-12
© 2016 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • SuperSeal™ Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
