PR
E
CI
PIN RECEPTACLES
for .040” - .050” diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
0355
0354
3490
3808
0355-0-15-XX-02-XX-10-0
Solder mount in .102 min.
mounting hole
0354-0-15-XX-02-XX-10-0
Pentagonal press-fit in .104 min.
plated thru hole
3490-0-15-XX-02-XX-10-0
Press-fit in .091 mounting hole
3808-0-15-XX-02-XX-10-0
Press-fit in .090 mounting hole
9184
.156 DIA.
.130 DIA.
.090 DIA.
.100
.070
.083
.160
.190
9222
.156 DIA.
.120 DIA.
.080 DIA.
.055
.200
.125
.173
.083
9184-0-15-XX-02-XX-40-0
Bottom entry, surface mount
.092 min. plated thru hole.
Also available on carrier tape,
Order as: 9184-0-57-XX-02-XX-40-0
9222-2-15-XX-02-XX-40-0
Bottom entry, surface mount
.082 min. plated thru hole
Also available on carrier tape,
Order as: 9222-2-57-XX-02-XX-40-0
Carrier tape format for
9184 & 9222.
1,500 pieces per 13” reel
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±.005
DIAMETERS: ±.002
ANGLES:
± 2°
ORDER CODE: XXXX - X - 15 - XX - 02 - XX - 10 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL
15
10μ” GOLD OVER NICKEL
RoHS
SPECIFY CONTACT FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL
27
30μ” GOLD OVER NICKEL
2002/95/EC
CONTACT
#02
CONTACT (DATA ON PAGE 223)
w w w. m i l l - m a x . c o m
156
516-922-6000
