REVISIONS
REV.
01
02
03
04
05
UPDATE DRAWING
ADD NOTE FOR SUPPORTING LEAD FREE VERSION
UPDATE DRAWING AS PER CUSTOMER REQUEST
UPDATE DRAWING
DESCRIPTION
FIRST RELEASE FOR RFQ#A02-5478
ECN NO.
N/A
EE3486
EE4170
EE10250
EE11367
DATE
11/21/02
03/28/03
09/19/03
04/10/08
08/25/09
PAGE 4 IS FOR INTERNAL USE ONLY
PART NUMBER
832-00261
832-00261F
PART DESCRIPTION
Standard version, with Lead(Pb)
RoHS compliant per EU Directive 2002/95/EC(without exemption of solder content)
UNLESS OTHERWISE
SPECIFIED, DIMENSIONS
ARE IN INCH/mm.
TITLE
COMMON MODE CHOKE, VERTICAL
MOUNT, THRU HOLE, 4 PIN
APPROVALS
DRAWN BY
DATE
08/25/09
WARNING !
E & E Magnetic Products Ltd.
DRAWING NO./MODEL
REV
C. LAU
PROJ. ENG
For
ALL SHEETS OF THIS DOCUMENT ARE
CONTROLLED DOCUMENTATION AND
TOLERANCE ARE:
ARE NOT TO BE RELEASED OUTSIDE
INCH
mm
ANGLE
OF E&E OR ITS SUB-CONTRACTORS
.XXX ± .005 .XX ± .13 X.X ± 0.3
WITHOUTAUTHORIZATION.
.XX ± .02
.X ± .5
X. ± 1
C. LAU
APPROVED BY
08/25/09
08/25/09
08/25/09
SCALE
V. TSUI
Q.A.
832-00261
PAGE
OF
05
1
4
C.M. TSUI
DO NOT SCALE
4
EE
831-00XXX
832-00261
(DATE)
(DATE)
1.250 Max
31.75
1
.200±.010
5.08±0.25
1.380 Max
35.00
4
4
3
.827
21.00 Max
1
4
.600±.010
15.24±0.25
.600
15.24
Dia: .065
1.65
2
.900±.010
22.86±0.25
3
Dia: .055 Max
1.40
.900
22.86
Recommended
Pad Layout
MECHANICAL OUTLINE
1. Dimensions are specified in
inches
with higher precedence in mm.
mm
2. Unless otherwise specified, all tolerances are ±
.010
.
0.25
3. "(DATE)" includes at least the manufacturing date code(in YYWW format) plus two
character country code.
4. For RoHS compliant version, 832-00261F, the part will be marked with “832-00261F”,
instead of “832-00261”.
E & E Magnetic Products Ltd.
DRAWING NO./MODEL
REV
832-00261
SCALE
PAGE
OF
05
2
4
DO NOT SCALE
FREQUENCY
1
2
3
4
5
6
7
8
10 kHz
50 kHz
100 kHz
300 KHz
1 MHz
5 MHz
10 MHz
993.397.694 kHz
IMPEDANCE
125.37
Ω
TYP
609.86 k
Ω
TYP
1.2465 k
Ω
TYP
2.9187 k
Ω
TYP
4.1184 k
Ω
TYP
2.8914 k
Ω
TYP
2.0993 k
Ω
TYP
4.1191 k
Ω
TYP
Frequency
Impedance vs Frequency Curve
ELECTRICAL SPECIFICATION @25
°
C:
PARAMETERS
Turn Ratio(1-2):(4-3) @100kHz, 1Vrms
Polarity(1-2):(4-3)
Inductance, Ls(1-2) and Ls(4-3) @100kHz, 0.1Vrms
DCR(Each Winding), for reference only
Hipot(1-2):(4-3)
1
UNIT
-
-
mH
mΩ
Vrms
4
LIMITS
1:1 ± 2%
Per Schematic
1.5 Min
25 Max
1500 Min
2
3
SCHEMATIC
E & E Magnetic Products Ltd.
DRAWING NO./MODEL
REV
5. Rated current: 10Arms and rated voltage is 250Vac, 50/60Hz.
6. Operating temperature range: -20°C to +85°C.
7. The part temperature (ambient temperature + temperature rise) should not exceed the
upper limit of the operating temperature under worst case operating conditions. Circuit
design, component placement, PWB trace size and thickness, airflow and other
cooling provisions all affect the part temperature. Part temperature should be verified
in the end application.
832-00261
SCALE
PAGE
OF
05
3
4
DO NOT SCALE
1.200 Max
30.48
.650
16.51 Max
4
EE
831-00XXX
832-00261
(DATE)
(DATE)
1.250 Max
31.75
1
.200±.010
5.08±0.25
1.380 Max
35.00
4
4
3
Frequency
.827
21.00 Max
Impedance vs Frequency Curve
4
FREQUENCY
1
2
3
10 kHz
50 kHz
100 kHz
300 KHz
1 MHz
5 MHz
10 MHz
993.397.694 kHz
IMPEDANCE
125.37
Ω
TYP
609.86 k
Ω
TYP
1.2465 k
Ω
TYP
2.9187 k
Ω
TYP
4.1184 k
Ω
TYP
2.8914 k
Ω
TYP
2.0993 k
Ω
TYP
4.1191 k
Ω
TYP
1
1
.600±.010
15.24±0.25
4
2
.900±.010
22.86±0.25
3
Dia: .055 Max
1.40
4
2
3
5
6
7
8
ELECTRICAL SPECIFICATION @25
°
C:
PARAMETERS
Turn Ratio(1-2):(4-3) @100kHz, 1Vrms
Polarity(1-2):(4-3)
Inductance, Ls(1-2) and Ls(4-3) @100kHz, 0.1Vrms
DCR(Each Winding), for reference only
Hipot(1-2):(4-3)
SCHEMATIC
UNIT
-
-
mH
mΩ
Vrms
LIMITS
1:1 ± 2%
Per Schematic
1.5 Min
25 Max
1500 Min
FOR PRODUCTION USE
E & E Magnetic Products Ltd.
DRAWING NO./MODEL
REV
8. Dimensions are specified in
inches
mm
with higher precedence in mm.
SCALE
832-00261
PAGE
OF
05
4
4
9. Unless otherwise specified, all tolerances are ±
.010
.
0.25
DO NOT SCALE
