TYPE 40Z - SMD TRANSFORMER MODULES

Dual Port 10/100 Base-Tx

FEATURES

Products matched to most IC manufacturers.

Designed to meet insertion loss and return loss

requirements of IEEE 802.3u.

40 Pin low profile SMD package for Pick and Place

manufacturing.

Common footprints & pinouts.

PACKAGE

1.120

28.45

SCHEMATIC A

SCHEMATIC B

SCHEMATIC C

VITEC

40Z43xx

0.018

0.46

0.050

1.27

0.625

15.88

0.006

0.15

0.480

12.19

0.015

0.38

0.225

5.72

0.950

24.13

Drawing NOT to Scale. Dimensions Inches/mm +/- 0.005/0.127 Unless noted.

ELECTRICAL CHARACTERISTICS @ 25

Part

Number

40Z4340

40Z4341

40Z4342

40Z4343

40Z4344

40Z4345

40Z4346

40Z4347

40Z4348

40Z4349

Notes: .

T-600.5

05/01

Turns

Ratio

XMT

+/- 5%

RCV

+/- 5%

MIN

Cross

Talk

MIN

CMR

TYP

Circuit

Position

Rx-Tx, Rx-Tx

Tx-Rx, Tx-Rx

Rx-Tx, Rx-Tx

Tx-Rx, Tx-Rx

Rx-Tx, Rx-Tx

Tx-Rx, Tx-Rx

Rx-Tx, Rx-Tx

Tx-Rx, Tx-Rx

Rise

Time

TYP

MAX

TYP

DCR

Ohms

MAX

Dielectric

Test

Vrms

MIN

Schem.

1CT:1CT

2CT:1CT

1.25CT:1CT

1CT:1.41CT

1.41CT:1CT

1.25CT:1CT

1CT:1CT

350

-38

-40

2.5

0.4

0.9

1500

Vitec Electronics Corporation

www.VitecCorp.com
