DIW3016

Description
DC-DC Regulated Power Supply Module, DIP-23/8
CategoryPower/power management    The power supply circuit
File Size274KB,8 Pages
ManufacturerDelta Electronics
Download Datasheet Parametric View All

DIW3016 Overview

DC-DC Regulated Power Supply Module, DIP-23/8

DIW3016 Parametric

Parameter NameAttribute value
Parts packaging codeDIP
package instructionDIP-23/8
Contacts23/8
Reach Compliance Codecompliant
ECCN codeEAR99
Analog Integrated Circuits - Other TypesDC-DC REGULATED POWER SUPPLY MODULE
JESD-30 codeR-XDMA-P8
Number of terminals8
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
Certification statusNot Qualified
surface mountNO
Terminal formPIN/PEG
Terminal locationDUAL
Base Number Matches1
FEATURES
Efficiency up to 86%
Industry standard form factor and pinout
Size:
31.8 x20.3 x10.2mm (1.25” x0.80” x0.40”)
Input: 5V, 12V, 24V, 48V (2:1)
Output: 3.3, 5, 12, 15,
±5, ±12, ±15V
Low ripple and noise
1500V isolation
UL 94V-0 Package Material
ISO 9001 and ISO14001 certified
manufacturing facility
CSA 60950-1 Recognized
Delphi DIW3000 Series DC/DC Power
Modules: 5, 12, 24, 48Vin, 5~6W DIP
The Delphi DIW3000, 5V, 12V, 24V, and 48V 2:1 wide input, single or
dual output, DIP form factor, isolated DC/DC converter is the latest
offering from a world leader in power systems technology and
manufacturing
Delta Electronics, Inc. The DIW3000 series operate
from 5V, 12V, 24V, or 48V (2:1) and provides 3.3V, 5V, 12V, or 15V
of single output or
±
5V,
±
12V, or
±
15V of dual output in an industrial
standard, metal case encapsulated DIP package (body size: 1.25"x
0.80”x0.40”). This series provides up to 6W of output power with
1500V isolation and a typical full-load efficiency up to 86%. With
creative design technology and optimization of component
placement, these converters possess outstanding electrical and
thermal performance, as well as extremely high reliability under
highly stressful operating conditions.
OPTIONS
APPLICATIONS
Industrial
Transportation
Process/ Automation
Telecom
Data Networking
DATASHEET
DS_DIW3000_12032008
