MKP1848 DC-Link
www.vishay.com
Vishay Roederstein
Metallized Polypropylene Film Capacitors
DC-Link Capacitor
FEATURES
•
•
•
•
•
•
•
High performance DC filter
Low ESR
High peak current capabilities
High RMS current capabilities
AEC-Q200 qualified
Mounting: Radial
Material categorization:
For definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
•
•
•
•
•
High performance DC filtering
HEV/EV: i.e. power train and OBC
Renewable energies inverters
Motor drives
Power supplies
QUICK REFERENCE DATA
Rated capacitance range
Capacitance tolerance
Rated voltage range, U
NDC
Climatic testing class
Rated temperature
Maximum permissible case temperature
Maximum applicable peak to peak ripple voltage
Reference standards
Dielectric
Electrodes
Construction
Encapsulation
Terminals
Self inductance (L
S
)
Withstanding DC voltage between terminals
Insulation resistance
Life time expectancy
Marking
(1)
1 μF to 400 μF
5%
450 V to 1200 V
40/105/56
85 °C
105 °C, observing voltage derating
0.2 x U
NDC
IEC 61071, IEC 60068
Polypropylene film
Metallized dielectric capacitor
Mono construction
Plastic case, sealed with resin; flame retardant
Tinned wires
< 1 nH per mm of lead spacing
1.5 U
NDC
for 10 s, cut off current 10 mA, rise time
1000 V/s
RC between leads, after 1 min > 10 000 s
For U
NDC
500 V measuring voltage 100 V
For U
NDC
> 500 V measuring voltage 500 V
Useful life time: > 100 000 h at U
NDC
and 70 °C
FIT: < 10 x 10
-9
/h (10 per 10
9
component h) at 0.5 x U
NDC
, 40 °C
C-value; tolerance; rated voltage; code for dielectric material;
code for manufacturing origin; manufacturer’s type designation;
manufacturer’s logo; year and week of manufacture
Notes
• For more detailed data and test requirements, contact
dc-film@vishay.com
• For general information like characteristics and definitions used for film capacitors follow the link:
www.vishay.com/doc?28147
(1)
See document “Voltage Proof Test for Metalized Film Capacitors” (www.vishay.com/doc?28169)
DC VOLTAGE RATINGS
U
NDC
at 85 °C
U
OPDC
at 70 °C
U
OPDC
at 105 °C
Revision: 13-Nov-12
450 V
500 V
300 V
700 V
800 V
500 V
800 V
900 V
570 V
900 V
1100 V
650 V
1100 V
1350 V
800 V
1200 V
1500 V
850 V
Document Number: 28164
1
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848 DC-Link
www.vishay.com
COMPOSITION OF CATALOG NUMBER
MULTIPLIER
(nF)
10
100
1000
10 000
4
5
6
7
512
612
712
CAPACITANCE
(numerically)
Example:
1200 nF
12 000 nF
120 000 nF
1.2 µF
12 µF
120 µF
P1
(mm)
27.5
37.5
52.5
PITCH
CODE
K
P
Y
Vishay Roederstein
MKP 1848
6
12
09
4
P
4
SPECIAL CODE FOR TERMINAL
2
4
5
(1)
TYPE CONSTRUCTION
METALLIZED POLYPROPYLENE
VOLTAGE
U
N
= 45 = 450 V
DC
U
N
= 70 = 700 V
DC
U
N
= 08 = 800 V
DC
U
N
= 09 = 900 V
DC
U
N
= 91 = 1100 V
DC
U
N
= 92 = 1200 V
DC
Note
(1)
Tabs terminals or customized terminals are available on request
TOLERANCE
4
±5%
2 pins
4 pins P2 = 10.2 mm
4 pins P2 = 20.3 mm
Customized
DIMENSIONS
in millimeters
2 PINS
w
I
h
P1
6-1
Ø dt
P1 ± 0.4 - PCM 27.5 mm
P1 ± 0.5 - PCM ≥ 37.5 mm
4 PINS
I
Marking
P2
P2
h
w
P1
Ø dt
P1 ± 0.5
6-2
P2 ± 0.5
Revision: 13-Nov-12
Document Number: 28164
2
For technical questions, contact:
dc-film@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MKP1848 DC-Link
www.vishay.com
Vishay Roederstein
6 PINS
I
Marking
P2
h
P2
w
DIMENSIONS
in millimeters
P1
l
t
P1
Ø dt
P2
2 x P2
12 PINS
I
Marking
w
P1
h
P2
2 x P2
3 x P2
4 x P2
5 x P2
P1
l
t
Ø dt
P2
2 x P2
3 x P2
4 x P2
5 x P2
Note
• Ø dt ± 10 % of standard diameter specified
ELECTRICAL DATA AND ORDERING CODE
U
NDC
AT CAP.
(8)
85 °C
(μF)
(V)
DIMENSION
(5)
(mm)
w
h
l
P1
(mm)
P2
(mm)
dV/dt I
PEAK
(V/μs) (A)
I
RMS (2)
(A)
ESR
(3)
(m)
tan
10 kHz
(< 10
-4
)
(4)
ORDERING CODE
(1)
2
4
2
4
2
4
PINS PINS PINS PINS PINS PINS
2.5
3
4
4
5
6
6.5
8.5
8.5
9
10
11.5
7.5
-
-
-
-
-
-
-
-
-
-
-
-
8
54
34.5
23.0
20.5
16.5
13.5
11.5
8.5
9.0
8.0
7.0
6.0
13.5
-
-
-
-
-
-
-
-
-
-
-
-
12.0
85
85
85
85
85
85
85
85
85
85
85
85
160
-
-
-
-
-
-
-
-
-
-
-
-
140
MKP1848510454K2
MKP1848520454K2
MKP1848530454K2
MKP1848540454K2
MKP1848550454K2
MKP1848560454K2
MKP1848570454K2
MKP1848580454K2
MKP1848590454K2
MKP1848610454K2
MKP1848612454K2
MKP1848615454K2
MKP1848610454P*
U
OPDC
AT 70 °C = 500 V, U
OPDC
AT 105 °C = 300 V
1
2
3
4
5
450
6
7
8
9
10
12
15
10
9.0
9.0
11.0
11.0
13.0
15.0
15.0
18.0
18.0
18.0
21.0
20.0
18.5
19.0
19.0
21.0
21.0
23.0
25.0
25.0
28.0
28.0
28.0
31.0
35.0
35.5
32.0
32.0
32.0
32.0
32.0
32.0
32.0
32.0
32.0
32.0
32.0
32.0
43.0
27.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
37.5
-
-
-
-
-
-
-
-
-
-
-
-
10.2
75
75
75
75
75
75
75
75
75
75
75
75
40
75
150
225
300
375
450
525
600
675
750
900
1125
400
