High Intensity AlInGaP
LED Lamps
Technical Data
SunPower Series
HLMP-WLxx
HLMP-NL06
HLMP-WHxx
HLMP-NH04
HLMP-WGxx
HLMP-NG07
Features
• T-1 (3 mm) and T-1
3
/
4
(5 mm) General Purpose
LED Lamps
• AlInGaP
SunPower
Intensity
• High Light Output
• Clear and Tinted Diffused
Lens Options
• Narrow and Wide Viewing
Angles
• Amber, Red-Orange, and Red
• Available on Tape and Reel
Description
This family of 3 mm and 5 mm
LED lamps is specially designed
for applications requiring higher
levels of intensity than is
achieved with a standard lamp.
The 5 mm lamp is available with
15, 30, and 65 degree viewing
angle options. The 3 mm lamp is
available with a 60 degree
viewing angle.
Applications
• General Purpose
• Consumer Goods
• Indicator Lights
Device Selection Guides
T-1
3/4
(5 mm) Lamp
Color
Part Number
Amber
HLMP-WL12
Amber
HLMP-WL27
Amber
HLMP-WL02
Red Orange
HLMP-WH12
Red Orange
HLMP-WH27
Red Orange
HLMP-WH02
Red
HLMP-WG12
Red
HLMP-WG27
Red
HLMP-WG02
T-1 (3 mm) Lamp
Color
Part Number
Amber
HLMP-NL06
Red Orange
HLMP-NH04
Red
HLMP-NG07
Package
Diff.
Tint
Luminous Intensity
Min. mcd, If @ 20 mA
450
205
35
270
155
35
270
155
26
Luminous Intensity
Min. mcd, If @ 20 mA
96.2
90.2
90.2
Viewing Angle
2
θ
1/2
(Degrees)
15
30
65
15
30
65
15
30
65
Viewing Angle
2θ
1/2
(Degrees)
60
60
60
X
X
X
X
X
X
Package
Diff.
Tint
2
Technical Data
Amber
(λ
d
= 590 nm)
[1]
Minimum
Luminous
Part
Intensity
No.
I
v
(mcd)
[3,4]
,
HLMP-
@ 20 mA
WL12
450
WL27
205
WL02
35
NL06
96.2
Red-Orange
(λ
d
= 615 nm)
[1]
Minimum
Luminous
Part
Intensity
No.
I
v
(mcd)
[3,4]
,
HLMP-
@ 20 mA
WH12
270
WH27
155
WH02
35
NH04
90.2
Red
(λ
d
= 626 nm)
[1]
Minimum
Luminous
Part
Intensity
No.
I
v
(mcd)
[3,4]
,
HLMP-
@ 20 mA
WG12
270
WG27
155
WG02
26
NG07
90.2
Typical
Viewing
Angle, 2θ
1/2
(Deg.)
[2]
15
30
65
60
Epoxy
clear
clear
tinted
diffused
[5]
clear
B/3 mm
Package
Drawing/
Nominal
Diameter
A/5 mm
A/5 mm
A/5 mm
Notes:
1. Dominant Wavelength,
λ
d
, is derived from the CIE Chromaticity Diagram, and represents the color of the lamp.
2.
Θ
1/2
is the off-axis angle where the luminous intensity is one half the on-axis intensity.
3. The luminous intensity is measured on the mechanical axis of the lamp package.
4. The optical axis is closely aligned with the package mechanical axis.
5. Tinting of amber lamps is yellow, red-orange lamps are tinted a reddish orange, and red lamps are tinted red.
Package Dimensions
A
3.80 ± 0.30
5.00 ± 0.20
(0.197 ± 0.008)
B
3.10 ± 0.20
8.71 ± 0.20
(0.343 ± 0.008
1.14 ± 0.20
(0.045 ± 0.008)
3.35 ± 0.30
5.70 ± 0.5
2.00
2.35 (0.093)
MAX.
31.60
(1.244) MIN.
0.70 (0.028)
MAX.
0.8 MAX.
(MENISCUS)
0.65 MAX.
23.0 MIN.
CATHODE
LEAD
5.80 ± 0.20
(0.228 ± 0.008)
CATHODE
FLAT
2.54 ± 0.38
(0.100 ± 0.015)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
1.0 MIN.
0.44 ± 0.2
1.00 MIN.
(0.039)
3.60
2.54 ± 0.3
0.4
+ 0.1
–0
3
Absolute Maximum Ratings at T
A
= 25
°
C
Parameter
DC Forward Current
Peak Pulsed Forward Current
[3,4]
Average Forward Current
Reverse Voltage (I
R
= 100
µA)
LED Junction Temperature
Operating Temperature
Storage Temperature
Dip/Drag Solder Temperature
Wave Solder Temperature
5 mm
3 mm
50 mA
[1,3,4]
30 mA
[2,3,4]
70 mA
50 mA
30 mA
30 mA
5V
5V
130°C
110°C
-40°C to +100°C
-40°C to +80°C
-40°C to +120°C
-40°C to +85°C
260°C for 5 seconds
245°C for 3 seconds
[1.59 mm (0.060 in.) below seating plane]
Notes:
1. Derate linearly as shown in Figure 4.
2. Derate linearly as shown in Figure 5.
3. For long term performance with minimal light output degradation, drive currents between 10 and 30 mA are recommended.
4. Please contact your Agilent sales representative about operating currents below 10 mA.
Electrical/Optical Characteristics at T
A
= 25
°
C
Parameter
Forward Voltage
Amber (λ
d
= 590 nm)
Red-Orange (λ
d
= 615 nm)
Red (λ
d
= 626 nm)
Reverse Voltage
Peak Wavelength
Amber
Red-Orange
Red
Spectral Halfwidth
Symbol
Min.
Typ.
2.02
1.94
1.90
20
592
621
635
17
Max.
Units
Test Conditions
I
F
= 20 mA
V
F
V
R
λ
PEAK
∆λ
1/2
5
2.4
V
V
I
R
= 100
µA
Peak of Wavelength of
Spectral Distribution
at I
F
= 20 mA
Wavelength Width at
Spectral Distribution
1
/
2
Power point at
I
F
= 20 mA
Exponential Time
Constant, e
-t/τs
V
F
= 0, f = 1 MHz
LED Junction-to-Cathode
Lead
Emitted Luminous
Power/Emitted Radiant
Power
nm
nm
Speed of Response
Capacitance
Thermal Resistance
Luminous Efficacy
[5]
Amber
Red-Orange
Red
τ
s
C
RΘ
J-PIN
20
40
240
ns
pF
°C/W
η
v
500
235
155
lm/W
Note:
1. The radiant intensity, I
e
, in watts per steridian, may be found from the equation I
e
= I
v
/η
v
, where I
v
is the luminous intensity in
candelas and
η
v
is the luminous efficacy in lumens/watt.
4
1.0
AMBER
RELATIVE INTENSITY
RED-ORANGE
RED
CURRENT – mA
70
60
AMBER
50
40
30
RED
20
10
0.5
0
550
600
WAVELENGTH – nm
650
700
0
1.0
1.5
2.0
2.5
3.0
V
F
– FORWARD VOLTAGE – V
Figure 1. Relative Intensity vs. Peak Wavelength.
Figure 2. Forward Current vs.
Forward Voltage.
3.0
RELATIVE LUMINOUS INTENSITY
(NORMALIZED AT 20 mA)
2.5
2.0
1.5
1.0
0.5
0
I
F
– FORWARD CURRENT – mA
50
40
Rθ
JA
= 585° C/W
30
Rθ
JA
= 780° C/W
20
10
0
0
20
40
60
0
20
40
60
80
100
I
F
– DC FORWARD CURRENT – mA
T
A
– AMBIENT TEMPERATURE – °C
Figure 3. Relative Luminous Intensity
vs. Forward Current.
Figure 4. Maximum Forward Current
vs. Ambient Temperature for 5 mm
Lamps. Derating Based on T
JMAX
=
130
°
C.
I
F
– FORWARD CURRENT – mA
30
Rθ
JA
= 500° C/W
20
Rθ
JA
= 660° C/W
10
0
0 10 20 30 40 50 60 70 80 90
T
A
– AMBIENT TEMPERATURE – °C
Figure 5. Maximum Forward Current
vs. Ambient Temperature for 3 mm
Lamps. Derating Based on T
JMAX
=
110
°
C.
5
1.0
0.9
RELATIVE INTENSITY – %
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-25
-20
-15
-10
-5
0
5
10
15
20
25
ANGULAR DISPLACEMENT – DEGREES
Figure 6. Representative Spatial Radiation Pattern for 15
°
Viewing Angle T-1
3/4
(5 mm) Lamps (HLMP-WX12).
1.0
0.9
RELATIVE INTENSITY – %
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-25
-20
-15
-10
-5
0
5
10
15
20
25
ANGULAR DISPLACEMENT – DEGREES
Figure 7. Representative Spatial Radiation Pattern for 30
°
Viewing Angle T-1
3/4
(5 mm) Lamps (HLMP-WX27).
1.0
NORMALIZED INTENSITY – %
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-100
-80
-60
-40
-20
0
20
40
60
80
100
ANGULAR DISPLACEMENT – DEGREES
Figure 8. Representative Spatial Radiation
Pattern for 65
°
Viewing Angle Tinted/Diffused
T-1
3/4
(5 mm) Lamps (HLMP-WX02).
