YH1322 Series OCXO
10 MHz – 120 MHz
GREENRAY INDUSTRIES, INC.
PRECISION QUARTZ TECHNOLOGY
Very Low Phase Noise
HCMOS or Sinewave Output
Ideal for Base Station or Test Equipment Apps
10.0 MHz to 120.0 MHz
Sinewave, +10dBm min into 50 ohms
-20dBc
Temp Range 10MHz Tol
Model
100MHz Tol
Model
-8
-8
B18
± 5x10
B58
0 to +50°C
± 1x10
-8
-8
-10 to +60°C
± 1.5x10
G158
± 7x10
G78
-8
-7
N28
± 1x10
N17
-20 to +70°C
± 2x10
-8
-7
T58
± 3x10
T37
-40 to +85°C
± 5x10
-9
±5x10 for a 5% change
-7
-7
±1x10 per year (10MHz); ±5x10 per year (100MHz)
+15 VDC ± 5% - Option C
+12 VDC ± 5% - Option D
Turn-on - < 6W for 5 minutes
Idle - < 2.5W @ +25°C
-8
within ± 5x10 in 5 minutes, ref to 60 minute frequency @ +25°C
10MHz Std
10MHz Ultra-Low
100MHz Std
100MHz Ultra-Low
-125 dBc/Hz
-128 dBc/Hz
-85 dBc/Hz
-90 dBc/Hz
-150 dBc/Hz
-155 dBc/Hz
-115 dBc/Hz
-120 dBc/Hz
-160 dBc/Hz
-163 dBc/Hz
-145 dBc/Hz
-150 dBc/Hz
-165 dBc/Hz
-168 dBc/Hz
-160 dBc/Hz
-165 dBc/Hz
-165 dBc/Hz
-168 dBc/Hz
-165 dBc/Hz
-168 dBc/Hz
±1.0 ppM typ, positive slope
+0.5 to +5.0V EFC
MIL-STD-202, Method 213, Condition C
MIL-STD-202, Method 204, Condition A
(Rev H)
SPECIFICATIONS
Frequency
Output
Harmonics
Temp Stability
Freq vs. Supply
Aging
Input Voltage
Input Power
Warm-up Time
Phase Noise
(Sine Max)
10 Hz
100 Hz
1 kHz
10 kHz
100 kHz
Frequency Adjust
Shock (optional)
Vibration (optional)
Ordering Example: YH1322 - N28 - D - UL - 10.0MHz
(Model# - Stability – Input V - Phase Noise Opt - Frequency)
PIN CONNECTIONS
1 - EFC
2 - Input Voltage
3 - 0V, Case Gnd
J1 - Output
To inquire about available custom parameters, please contact us at
sales@greenrayindustries.com.
840 West Church Rd., Mechanicsburg, PA 17055
Tel: 717-766-0223 Fax: 717-790-9509
www.greenrayindustries.com email: sales@greenrayindustries.com
