Power Splitter/Combiner
2 Way-90°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
SMA Connectorized
ZX10Q-2-12+
50Ω
-40°C to 85°C
-55°C to 100°C
20W* max.
800 to 1250 MHz
Features
• low insertion loss, 0.4 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected by U.S Patent 6,790,049
Maximum Ratings
CASE STYLE: GW1052
Connectors Model
SMA
ZX10Q-2-12-S+
Price
$29.95
Qty.
(1-24)
* Derate linearly to 7W at 100°C ambient.
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
INPUT PORT
PORT 1 (+90°)
PORT 2 (0°)
50 OHM TERM EXTERNAL**
1
2
3
4
Applications
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
• cellular
• GSM
• balanced amplifiers
• modulators
FREQ.
RANGE
(MHz)
f
L
-f
U
800-1250
800-1000
1000-1250
Electrical Specifications (T
AMB
=25°C)
INSERTION LOSS (dB)
Avg. of Coupled Outputs
ABOVE 3 dB
Typ.
0.3
0.4
Max.
0.6
0.7
ISOLATION
(dB)
Typ.
17
16
Min.
15
13
PHASE
UNBALANCE
(Degrees)
Typ.
2.5
2.5
Max.
5.0
5.0
AMPLITUDE
UNBALANCE
(dB)
Typ.
0.2
0.5
Max.
0.8
0.8
Typical Performance Data
** Recommended external termination
Mini-Circuits Part. No. ANNE-50L
Frequency
(MHz)
Total Loss
1
(dB)
S-1
800.00
825.00
850.00
875.00
925.00
950.00
975.00
1000.00
1050.00
1075.00
1100.00
1150.00
1175.00
1225.00
1250.00
3.13
3.20
3.27
3.33
3.44
3.48
3.52
3.56
3.61
3.63
3.65
3.65
3.65
3.62
3.60
S-2
3.59
3.51
3.44
3.38
3.28
3.24
3.20
3.17
3.14
3.13
3.13
3.14
3.16
3.22
3.26
Amplitude
Unbalance
(dB)
0.46
0.31
0.18
0.05
0.16
0.25
0.32
0.39
0.48
0.50
0.52
0.51
0.49
0.40
0.34
Isolation
(dB)
Phase
Unbalance
(deg.)
87.58
87.64
87.73
87.82
87.99
88.10
88.21
88.35
88.65
88.81
88.98
89.40
89.65
90.21
90.53
VSWR
S
VSWR
1
VSWR
2
Outline Drawing
16.94
16.91
16.86
16.82
16.72
16.66
16.59
16.51
16.31
16.20
16.08
15.80
15.64
15.28
15.08
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.27
1.28
1.28
1.29
1.29
1.30
1.31
1.20
1.20
1.19
1.18
1.16
1.15
1.14
1.13
1.10
1.09
1.07
1.05
1.03
1.01
1.03
1.11
1.10
1.10
1.09
1.08
1.07
1.07
1.07
1.07
1.07
1.07
1.09
1.10
1.12
1.14
1. Total Loss = Insertion Loss + 3dB splitter loss.
TOTAL LOSS
4.5
S-1
TOTAL LOSS (dB)
4.0
3.5
3.0
2.5
2.0
800
S-2
ISOLATION (dB)
17.5
17.0
16.5
16.0
15.5
15.0
14.5
800
ISOLATION
Outline Dimensions (
inch
)
mm
A
1.04
26.42
H
.25
6.35
B
.60
15.24
J
.50
12.70
C
.75
19.05
K
.11
2.79
D
.50
12.70
L
.820
20.83
E
.10
2.54
M
.106
2.69
F
.17
4.32
G
.25
6.35
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
PHASE UNBALANCE
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
PHASE UNBALANCE (deg.)
N
wt.
.12 grams
3.05
21.0
electrical schematic
95
93
91
89
87
85
800
850
900
950 1000 1050 1100 1150 1200 1250
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. E
M127604
ZX10Q-2-12+
AD/CP/AM
120130
