IDC
CK
CONNECTOR
2.0mm
(.079") pitch
Disconnectable Insulation displacement connectors
Features ––––––––––––––––––––––––
• UL10272 wire is applicable
UL10272 wire has come to be applicable for 2.0mm (.079")
pitch IDC that enables to make multi-harness such as the
combination of CK connector (2.0mm (.079")pitch) and CZ
connector (1.5mm (.059") pitch). Selection of various
connectors is possible.
• Folded beam double-leaf contact construction
The contact springs are folded to increase their effective
strength. This design provides a safety margin that allows the
contacts to endure the distortion of misinsertion without being
permanently distorted.
• Twin U-slot insulation displacement section
The insulation displacement section connected to the wire
consists of two tin-plated slots (twin U-slot) for high reliability.
• Strain relief
Multi-harness of CK connector (2.0mm
(.079")) and CZ connector (1.5mm(.059"))
combination has been realized. The in-line
type IDC features low profile design with
6.9mm (.272") mounting height and 4.8mm
(.189") thick (top entry type).
The strain relief feature prevents stress caused by vibration,
impact or bending from effecting the insulation displacement
connection. This is accomplished by holding the outside of the
wire with the insulation gripping device on the housing. To
protect circuit integrity from vibration and undue tension, ample
clearance is provided between the insulation displacement
connection and the strain relief.
Specifications –––––––––––––––––––
• Current rating: 2A AC, DC (AWG #26)
• Voltage rating: 100V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m Ω max.
After environmental testing/20m Ω max.
• Insulation resistance:
1,000M Ω min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: UL1061, UL10272(Contact JST for details
regarding other UL wires.)
AWG #28, #26
Conductor/tin-plated annealed copper strands
Insulation O.D./0.75 to 1.05mm(.030" to .041")
• Applicable PC board thickness: 0.8 to 1.6mm(.031" to .063")
* Contact JST for details.
Standards ––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
243
CK
CONNECTOR
Receptacle –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Cir-
cuits
2
3
2.0(.079)
2.0(.079)
B
A
4.25(.167)
4
5
6
7
4.2(.165)
3.5(.138)
8
9
10
11
12
13
14
15
Reverse type
Circuit
No.1
Normal type
Circuit
No.1
5.15(.203)
Model No.
Normal type Reverse type
02CK-6H-P 02CK-6H-PC
03CK-6H-P 03CK-6H-PC
04CK-6H-P 04CK-6H-PC
05CK-6H-P 05CK-6H-PC
06CK-6H-P 06CK-6H-PC
07CK-6H-P 07CK-6H-PC
08CK-6H-P 08CK-6H-PC
09CK-6H-P 09CK-6H-PC
10CK-6H-P 10CK-6H-PC
11CK-6H-P 11CK-6H-PC
12CK-6H-P 12CK-6H-PC
13CK-6H-P 13CK-6H-PC
14CK-6H-P 14CK-6H-PC
15CK-6H-P 15CK-6H-PC
Dimensions mm(in.)
A
B
2.0( .079)
4.0( .157)
6.0( .236)
8.0( .315)
10.0( .394)
12.0( .472)
14.0( .551)
16.0( .630)
18.0( .709)
20.0( .787)
22.0( .866)
24.0( .945)
26.0(1.024)
28.0(1.102)
6.0( .236)
8.0( .315)
10.0( .394)
12.0( .472)
14.0( .551)
16.0( .630)
18.0( .709)
20.0( .787)
22.0( .866)
24.0( .945)
26.0(1.024)
28.0(1.102)
30.0(1.181)
32.0(1.260)
Q'ty /
box
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
500
Single-row shrouded header (Through-hole type) ––––––––––––––––––––––––––––––
Top entry type
(2 circuits)
B
4.5(0.177)
1.7(.067)
6.0(.236)
3.4(.134)
Reverse type
Circuit
No.1
Side entry type
4.8(.189)
B
1.7(.067)
6.25(.246)
6.0(.236)
1.6(.063)
Reverse type
Circuit
No.1
1.95(.077)
H JST
Material and Finish
Contact: Copper alloy, tin-plated
Housing: Glass-filled nylon 66
Cir-
cuits
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1.95 A
(.077)
Normal type
Circuit
No.1
0.5(.020)
(3 to 15 circuits)
B
Normal type Model No.
Top entry type (with a boss) Side entry type
B2B-PH-KBL-H
S2B-PH-KL
B3B-PH-KBL-H
S3B-PH-KL
B4B-PH-KBL-H
S4B-PH-KL
B5B-PH-KBL-H
S5B-PH-KL
B6B-PH-KBL-H
S6B-PH-KL
B7B-PH-KBL-H
S7B-PH-KL
B8B-PH-KBL-H
S8B-PH-KL
B9B-PH-KBL-H
S9B-PH-KL
B10B-PH-KBL-H
S10B-PH-KL
B11B-PH-KBL-H
S11B-PH-KL
B12B-PH-KBL-H
S12B-PH-KL
B13B-PH-KBL-H
S13B-PH-KL
B14B-PH-KBL-H
S14B-PH-KL
B15B-PH-KBL-H
S15B-PH-KL
Reverse type Model No.
Top entry type (with a boss) Side entry type
B2B-PH-KBLC-H
S2B-PH-KLC-H
B3B-PH-KBLC-H
S3B-PH-KLC-H
B4B-PH-KBLC-H
S4B-PH-KLC-H
B5B-PH-KBLC-H
S5B-PH-KLC-H
B6B-PH-KBLC-H
S6B-PH-KLC-H
B7B-PH-KBLC-H
S7B-PH-KLC-H
B8B-PH-KBLC-H
S8B-PH-KLC-H
B9B-PH-KBLC-H
S9B-PH-KLC-H
B10B-PH-KBLC-H
S10B-PH-KLC-H
B11B-PH-KBLC-H
S11B-PH-KLC-H
B12B-PH-KBLC-H
S12B-PH-KLC-H
B13B-PH-KBLC-H
S13B-PH-KLC-H
B14B-PH-KBLC-H
S14B-PH-KLC-H
B15B-PH-KBLC-H
S15B-PH-KLC-H
Dimensions mm(in.)
Q'ty / box
Top entry type Side entry type
A
B
2.0( .079)
4.0( .157)
6.0( .236)
5.9( .232)
7.9( .311)
9.9( .390)
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
250
250
250
1,000
1,000
500
500
500
500
250
250
250
250
250
250
250
200
8.0( .315) 11.9( .469)
10.0( .394) 13.9( .547)
12.0( .472) 15.9( .626)
14.0( .551) 17.9( .705)
16.0( .630) 19.9( .783)
18.0( .709) 21.9( .862)
20.0( .787) 23.9( .941)
22.0( .866) 25.9(1.020)
24.0( .945) 27.9(1.098)
26.0(1.024) 29.9(1.177)
28.0(1.102) 31.9(1.256)
Cir-
cuits
2
Reverse type
Circuit
No.1
2.0
(.079)
1.95
(.077)
A
0.5(.020)
Normal type
Circuit
No.1
Dimensions mm(in.)
Q'ty / box
A
B
Top entry type Side entry type
2.0( .079)
4.0( .157)
6.0( .236)
5.9( .232)
7.9( .311)
9.9( .390)
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
250
250
250
1,000
1,000
500
500
500
500
250
250
250
250
250
250
250
200
3
4
5
6
7
8
9
10
11
12
13
14
15
8.0( .315) 11.9( .469)
10.0( .394) 13.9( .547)
12.0( .472) 15.9( .626)
14.0( .551) 17.9( .705)
16.0( .630) 19.9( .783)
18.0( .709) 21.9( .862)
20.0( .787) 23.9( .941)
22.0( .866) 25.9(1.020)
24.0( .945) 27.9(1.098)
26.0(1.024) 29.9(1.177)
28.0(1.102) 31.9(1.256)
Material and Finish
3.4(.134)
0.5(.020)
2.0(.079)
A
Normal type
Circuit
No.1
Pin: Copper alloy, copper-undercoated, tin/lead-plated
Housing: Nylon 66, UL94V-0, gray
Note: Top entry type headers without bosses are also available.
