Module no:3003457 LabelId:3003457 Operator:Phoenix
18:45:47, Donnerstag, 28. Juni 2001
ZIK 2,5-L/L
Terminal width 6.2
(IEC)
[mm ]
IEC 947-7-1
Description
Three level installation terminal block,
with 2 phase
conductor connections
L
Three level installation terminal block,
with one phase
conductor connection
L
in the terminal center
Accessories
(1)
End cover
(2)
Fixed bridge,
for
cross-connections in the terminal
center, screw heads with insulating
collar, 10-pos., divisible, with 10
screws
(3)
Isolator bridge bar,
10-pos.,
divisible, with 10 screws, for switchable
branches with
(4)
Bridge bar isolator IS-K 4
as
distance piece
(5)
Partition plate,
for optical and
electrical separation of terminal block
groups, 2 mm thick
(7)
Screwdriver,
for actuating the
tension spring
(9)
Zack marker sheet, flat,
100-section, for labelling the outer
marker grooves
Technical data
Dimensions
Width / length / end cover width
Height (NS 35:7.5 / NS 35:15)
Technical data in accordance with IEC/
DIN VDE
Maximum load current / cross section
Rated surge voltage / contamination class
Surge voltage category / insulation material
[A] / [mm ]
[kV] / –
–/–
2
2
rigid
solid
0.2-4
flexible
stranded AWG
0.2-2.5
24-12
I
[A]
30
U
[V]
400
Type
ZIK 2,5-L/L
ZIK 2,5-L
Order No.
30 03 45 7
30 05 72 7
Pcs.
Pkt.
50
50
D-ZIK 2,5
FBI 10-6
30 00 93 9
I
max.
: 30 A
02 03 25 0
50
10
ISSBI 10-6
IS-K 4
ATP-ZIK
I
max.
: 26 A
03 01 50 5
13 02 33 8
30 06 46 7
10
100
50
SZF 1 - 0,6 x 3,5
ZBFM 6
(see
info)
12 04 51 7
1
[mm]
[mm]
6.2 / 118.5 / 2
51 / 58.5
30 / 4
6/3
III / I
Page 1 / 2
Phoenix Contact Elektronischer Katalog
Module no:3003457 LabelId:3003457 Operator:Phoenix
group
Connection capacity
stranded with ferrule with plastic sleeve
stranded with ferrule without plastic sleeve
stranded with TWIN ferrule with plastic
sleeve
Stripping length
Internal cylindrical gage (IEC 947-1:1988)
Insulation material
Inflammability class acc. to UL 94
Temperature indices RTI / Ti
Block diagram
[mm ]
[mm ]
[mm ]
[mm]
2
2
2
18:45:47, Donnerstag, 28. Juni 2001
0.25-2.5
0.25-2.5
0.5
10
A3
PA
V0
130 / 120
Phoenix Contact Elektronischer Katalog
Page 2 / 2
