MITSUBISHI MICROCOMPUTERS

M37273M8–XXXSP, M37273MF–XXXSP

M37273E8SP, M37273EFSP

SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER

and ON-SCREEN DISPLAY CONTROLLER

1. DESCRIPTION

The M37273M8-XXXSP and M37273MF-XXXSP are single-chip mi-

crocomputers designed with CMOS silicon gate technology. They

have a OSD, data slicer, and I

C-BUS interface, so it is useful for a

channel selection system for TV with a closed caption decoder.

The features of the M37273E8SP and M37273EFSP are similar to

those of the M37273M8-XXXSP and M37273MF-XXXSP except that

the chip has a built-in PROM which can be written electrically. The

difference between M37273M8-XXXSP and M37273MF-XXXSP are

the ROM size and RAM size. Accordingly, the following descriptions

will be for the M37273M8-XXXSP.

2. FEATURES

qNumber

of basic instructions .................................................... 71

qMemory

size

ROM .............. 32K bytes

(M37273M8-XXXSP, M37273E8SP)

60K bytes

(M37273MF-XXXSP, M37273EFSP)

RAM ............... 1152 bytes

(M37273M8-XXXSP, M37273E8SP)

1472 bytes

(M37273MF-XXXSP, M37273EFSP)

(*ROM correction memory included)

qMinimum

instruction execution time

......................................... 0.5

µs

(at 8 MHz oscillation frequency)

qPower

source voltage ................................................. 5 V

10 %

qSubroutine

nesting ............................................. 128 levels (Max.)

qInterrupts

....................................................... 17 types, 16 vectors

q8-bit

timers .................................................................................. 6

qProgrammable

I/O ports (Ports P0, P1, P2, P3

, P3

) ............. 26

qInput

ports (Ports P5

, P5

) ........................................................ 2

qOutput

ports (Ports P5

–P5

,P6) .............................................. 14

q12

V withstand ports ................................................................... 6

qLED

drive ports ........................................................................... 4

qSerial

I/O ............................................................ 8-bit

1 channel

qMulti-master

C-BUS interface .............................. 1 (2 systems)

qA-D

comparator (6-bit resolution) ................................ 6 channels

qPWM

output circuit ......................................................... 8-bit

qPower

dissipation

In high-speed mode ......................................................... 165 mW

(at V

= 5.5V, 8 MHz oscillation frequency, OSD on, and Data

slicer on)

In low-speed mode ......................................................... 0.33 mW

(at V

= 5.5V, 32 kHz oscillation frequency)

qROM

correction function ................................................ 2 vectors

qClosed

caption data slicer

qOSD

function

Display characters ................................... 32 characters

2 lines

(It is possible to display 3 lines or more by software)

Kinds of characters ........................................................ 254 kinds

Character display area ............................ CC mode: 16

26 dots

OSD mode: 16

20 dots

Kinds of character sizes ..................................... CC mode: 1 kind

OSD mode: 8 kinds

Kinds of character colors .................................. 8 colors (R, G, B)

Coloring unit ................... character, character background, raster

Display position

Horizontal: 128 levels

Vertical: 512 levels

Attribute ........................................................................................

CC mode: smooth italic, underline, flash, automatic solid space

OSD mode: border

Smoth roll-up

Window function

3. APPLICATION

TV with a closed caption decoder

Rev. 1.0
