Wire Guard |
Spacing 5.0 mm
AK104/..DS-5.0-V-GREY
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
4.0 mm²
0.2 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
10.70
15.70
20.70
25.70
30.70
35.70
40.70
45.70
50.70
55.70
60.70
Article Designation
AK104/2DS-5.0-V-GREY
AK104/3DS-5.0-V-GREY
AK104/4DS-5.0-V-GREY
AK104/5DS-5.0-V-GREY
AK104/6DS-5.0-V-GREY
AK104/7DS-5.0-V-GREY
AK104/8DS-5.0-V-GREY
AK104/9DS-5.0-V-GREY
AK104/10DS-5.0-V-GREY
AK104/11DS-5.0-V-GREY
AK104/12DS-5.0-V-GREY
Article Number
50104020070G
50104030070G
50104040070G
50104050070G
50104060070F
50104070070F
50104080070E
50104090070E
50104100070E
50104110070E
50104120070E
PU
250
250
250
250
200
200
100
100
100
100
100
Stranded with Ferrule 0.2 mm²
min
Stranded with Ferrule 2.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Wire Guard
Screw
Brass
Stainless Steel
Steel
7.0 mm
2.0 mm x 2.8 mm
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Colours
RAL7016
GREY , RAL7016
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
300 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
C
150 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
D
300 V
20 A
AWG 22-12
AWG 22-12
0.80 Nm
M3
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
32 A
max
4.0 mm²
4.0 mm²
0.50 Nm
M3
2.0 kV
www.ptr.eu
