5962-8773801GA amplifier basic information:
5962-8773801GA is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2
5962-8773801GA amplifier core information:
The minimum operating temperature of the 5962-8773801GA is -55 °C and the maximum operating temperature is 150 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum bias current at 25°C is: 0.004 µA Its maximum average bias current is 0.004 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-8773801GA is 0.25 V/us. The minimum slew rate of the 5962-8773801GA given by the manufacturer is 0.1 V/us. Its minimum voltage gain is 200000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-8773801GA gain becomes 0.707 times the low-frequency gain is 800 kHz.
The nominal supply voltage of 5962-8773801GA is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of the 5962-8773801GA is 60 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-8773801GA:
5962-8773801GA has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-8773801GA amplifier additional information:
5962-8773801GA adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low offset class of amplifiers. The frequency compensation status of 5962-8773801GA is: YES. Its temperature grade is: MILITARY. 5962-8773801GA is not Rohs certified.
The corresponding JESD-30 code is: O-MBCY-W8. The corresponding JESD-609 code is: e0. The material of the 5962-8773801GA package is mostly METAL. And its package shape is ROUND. The 5962-8773801GA package pin format is: CYLINDRICAL.
Its terminal form is: WIRE.
5962-8773801GA amplifier basic information:
5962-8773801GA is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2
5962-8773801GA amplifier core information:
The minimum operating temperature of the 5962-8773801GA is -55 °C and the maximum operating temperature is 150 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum bias current at 25°C is: 0.004 µA Its maximum average bias current is 0.004 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-8773801GA is 0.25 V/us. The minimum slew rate of the 5962-8773801GA given by the manufacturer is 0.1 V/us. Its minimum voltage gain is 200000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-8773801GA gain becomes 0.707 times the low-frequency gain is 800 kHz.
The nominal supply voltage of 5962-8773801GA is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of the 5962-8773801GA is 60 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-8773801GA:
5962-8773801GA has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-8773801GA amplifier additional information:
5962-8773801GA adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low offset class of amplifiers. The frequency compensation status of 5962-8773801GA is: YES. Its temperature grade is: MILITARY. 5962-8773801GA is not Rohs certified.
The corresponding JESD-30 code is: O-MBCY-W8. The corresponding JESD-609 code is: e0. The material of the 5962-8773801GA package is mostly METAL. And its package shape is ROUND. The 5962-8773801GA package pin format is: CYLINDRICAL.
Its terminal form is: WIRE.
| Parameter Name | Attribute value |
| Is it Rohs certified? | incompatible |
| Parts packaging code | BCY |
| package instruction | , CAN8,.2 |
| Contacts | 8 |
| Reach Compliance Code | unknown |
| ECCN code | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 0.004 µA |
| Maximum bias current (IIB) at 25C | 0.004 µA |
| Nominal Common Mode Rejection Ratio | 122 dB |
| frequency compensation | YES |
| Maximum input offset voltage | 60 µV |
| JESD-30 code | O-MBCY-W8 |
| JESD-609 code | e0 |
| low-dissonance | YES |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 1 |
| Number of terminals | 8 |
| Maximum operating temperature | 150 °C |
| Minimum operating temperature | -55 °C |
| Package body material | METAL |
| Encapsulate equivalent code | CAN8,.2 |
| Package shape | ROUND |
| Package form | CYLINDRICAL |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED |
| power supply | +-15 V |
| Certification status | Not Qualified |
| Filter level | 38535Q/M;38534H;883B |
| minimum slew rate | 0.1 V/us |
| Nominal slew rate | 0.25 V/us |
| Supply voltage upper limit | 22 V |
| Nominal supply voltage (Vsup) | 15 V |
| surface mount | NO |
| technology | BIPOLAR |
| Temperature level | MILITARY |
| Terminal surface | Tin/Lead (Sn/Pb) - hot dipped |
| Terminal form | WIRE |
| Terminal location | BOTTOM |
| Maximum time at peak reflow temperature | NOT SPECIFIED |
| Nominal Uniform Gain Bandwidth | 800 kHz |
| Minimum voltage gain | 200000 |
| Base Number Matches | 1 |
| 5962-8773801GA | 5962-8773801PA | 5962-8773803GA | 5962-8773803PA | 5962-8773803PX | 5962-8773803GX | |
|---|---|---|---|---|---|---|
| Description | IC OP-AMP, 60 uV OFFSET-MAX, 0.8 MHz BAND WIDTH, MBCY8, METAL CAN-8, Operational Amplifier | IC OP-AMP, 60 uV OFFSET-MAX, 0.8 MHz BAND WIDTH, CDIP8, HERMETIC SEALED, DIP-8, Operational Amplifier | IC OP-AMP, Operational Amplifier | IC OP-AMP, 60 uV OFFSET-MAX, 0.4 MHz BAND WIDTH, CDIP8, CERAMIC, DIP-8, Operational Amplifier | IC OP-AMP, 60 uV OFFSET-MAX, 0.4 MHz BAND WIDTH, CDIP8, CERAMIC, DIP-8, Operational Amplifier | IC OP-AMP, Operational Amplifier |
| package instruction | , CAN8,.2 | DIP, DIP8,.3 | , CAN8,.2 | DIP, DIP8,.3 | DIP, | , |
| Reach Compliance Code | unknown | unknow | unknown | unknown | unknown | unknown |
| ECCN code | EAR99 | EAR99 | EAR99 | EAR99 | EAR99 | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| JESD-609 code | e0 | e0 | e0 | e0 | e0 | e0 |
| Certification status | Not Qualified | Not Qualified | Not Qualified | Not Qualified | Not Qualified | Not Qualified |
| Terminal surface | Tin/Lead (Sn/Pb) - hot dipped | Tin/Lead (Sn/Pb) - hot dipped | Tin/Lead (Sn/Pb) - hot dipped | Tin/Lead (Sn/Pb) - hot dipped | TIN LEAD | TIN LEAD |
| Is it Rohs certified? | incompatible | incompatible | incompatible | incompatible | - | - |
| Parts packaging code | BCY | DIP | - | DIP | DIP | - |
| Contacts | 8 | 8 | - | 8 | 8 | - |
| Architecture | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | - | - |
| Maximum average bias current (IIB) | 0.004 µA | 0.004 µA | - | 0.004 µA | 0.004 µA | - |
| Maximum bias current (IIB) at 25C | 0.004 µA | 0.004 µA | 0.002 µA | 0.002 µA | - | - |
| Nominal Common Mode Rejection Ratio | 122 dB | 122 dB | - | 110 dB | 110 dB | - |
| frequency compensation | YES | YES | YES | YES | - | - |
| Maximum input offset voltage | 60 µV | 60 µV | 60 µV | 60 µV | 60 µV | - |
| JESD-30 code | O-MBCY-W8 | R-CDIP-T8 | O-MBCY-W8 | R-GDIP-T8 | R-GDIP-T8 | - |
| low-dissonance | YES | YES | YES | YES | - | - |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V | -15 V | -15 V | -15 V | - |
| Number of functions | 1 | 1 | 1 | 1 | 1 | - |
| Number of terminals | 8 | 8 | 8 | 8 | 8 | - |
| Maximum operating temperature | 150 °C | 150 °C | 125 °C | 125 °C | 125 °C | - |
| Minimum operating temperature | -55 °C | -55 °C | -55 °C | -55 °C | -55 °C | - |
| Package body material | METAL | CERAMIC, METAL-SEALED COFIRED | METAL | CERAMIC, GLASS-SEALED | CERAMIC, GLASS-SEALED | - |
| Encapsulate equivalent code | CAN8,.2 | DIP8,.3 | CAN8,.2 | DIP8,.3 | - | - |
| Package shape | ROUND | RECTANGULAR | ROUND | RECTANGULAR | RECTANGULAR | - |
| Package form | CYLINDRICAL | IN-LINE | CYLINDRICAL | IN-LINE | IN-LINE | - |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED | NOT SPECIFIED | NOT SPECIFIED | NOT SPECIFIED | - | - |
| power supply | +-15 V | +-15 V | +-15 V | +-15 V | - | - |
| Filter level | 38535Q/M;38534H;883B | 38535Q/M;38534H;883B | 38535Q/M;38534H;883B | MIL-STD-883 | MIL-STD-883 | - |
| minimum slew rate | 0.1 V/us | 0.1 V/us | 0.1 V/us | 0.1 V/us | - | - |
| Supply voltage upper limit | 22 V | 22 V | 22 V | 22 V | 22 V | - |
| Nominal supply voltage (Vsup) | 15 V | 15 V | 15 V | 15 V | 15 V | - |
| surface mount | NO | NO | - | NO | NO | - |
| technology | BIPOLAR | BIPOLAR | BIPOLAR | BIPOLAR | - | - |
| Temperature level | MILITARY | MILITARY | MILITARY | MILITARY | MILITARY | - |
| Terminal form | WIRE | THROUGH-HOLE | WIRE | THROUGH-HOLE | THROUGH-HOLE | - |
| Terminal location | BOTTOM | DUAL | BOTTOM | DUAL | DUAL | - |
| Maximum time at peak reflow temperature | NOT SPECIFIED | NOT SPECIFIED | NOT SPECIFIED | NOT SPECIFIED | - | - |
| Nominal Uniform Gain Bandwidth | 800 kHz | 800 kHz | - | 400 kHz | 400 kHz | - |
| Minimum voltage gain | 200000 | 200000 | 300000 | 300000 | - | - |
| Base Number Matches | 1 | 1 | 1 | 1 | 1 | - |
