AIH10H300 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> AIH10H300

AIH10H300: Description1-OUTPUT 250W DC-DC REG PWR SUPPLY MODULE, PACKAGE-18; CategoryPower/power management The power supply circuit; File Size139KB，2 Pages; ManufacturerEmerson Embedded Power

Download Datasheet Parametric View All

AIH10H300 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AIH10H300	-	-	View	Buy Now

AIH10H300 Overview

1-OUTPUT 250W DC-DC REG PWR SUPPLY MODULE, PACKAGE-18

AIH10H300 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	MODULE
package instruction	,
Contacts	18
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	420 V
Minimum input voltage	250 V
Nominal input voltage	300 V
JESD-30 code	R-XXMA-X18
JESD-609 code	e0
Maximum load regulation	0.2%
Number of functions	1
Output times	1
Number of terminals	18
Maximum operating temperature	100 °C
Minimum operating temperature	-20 °C
Maximum output voltage	28.8 V
Minimum output voltage	19.2 V
Nominal output voltage	24 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	UNSPECIFIED
Terminal location	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	250 W
Fine-tuning/adjustable output	YES
Base Number Matches	1

Preview

Download Datasheet

View All

Embedded Power for

Business-Critical Continuity

AIH Series

250 Watts

Total Power:

Input Voltage:

# of Outputs:

250 Watts

(12V @ 20.8A)

300V

Single

RoHS

Rev. 05.23.07

AIH Series

1 of 2

Electrical Specifications

Special Features

• 250W Continuous power at

100°C baseplate temperature

• High efficiency - up to 88%

• Low output ripple and noise

• Positive and Negative

enable function

• Excellent transient response

• Safety isolated low voltage

control and monitoring

• High reliability

• Wide input voltage range

• Paralleable with accurate

current sharing

• Adjustable output voltage

• Regulation to zero load

• Temperature monitor output

• EU Directive 2002/95/EC

compliant for RoHS

Input

Input range

Input surge

Efficiency

250 - 420 VDC

450V / 100ms

88% @ 5.0V (typical)

0.2% typical (5V and above); 10mV for below 5V

Output

Load Regulation

Line Regulation

Noise / ripple

100mV typical (below 5V); 2% typical (5V and above)

Output voltage adjust range +/-20% for 5V and above; +10%/ -50% for below 5V

Transient response

Current share accuracy

Overvoltage protection

Current limit

5% max for 3.3V and above150mV for 1.8V, deviation with 25%

to 75% full load 250 μS (max) recovery

3% typical

130% Vo (3.3 Vo and 5 Vo); 125% Vo (other Vo)

120% Io maximum

80 to 120% for 5V and above; +10% / -50% for below 5V

TTL compatible (positive & negative enable options)

3.3 to 5.5Vp-p @800 MHz ±5%

10mV/°K (2.73 = 0°C)

0 to 1mA (1mA = 100% Io rated)

Control

Voltage adjust

Enable

Clock input (external sync)

Temperature

monitor output

Current monitor output

Notes

Nominal values apply with sense pins disconnected and other control pin unconnected.

Safety

cUL

TUV

60950 Recognized

EN60950 Licensed

CE Mark
