3613C1R5K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 3613C1R5K

3613C1R5K: Description1 ELEMENT, 1.5uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT; CategoryPassive components inductor; File Size98KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

3613C1R5K Overview

1 ELEMENT, 1.5uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT

3613C1R5K Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	1812
Reach Compliance Code	unknown
ECCN code	EAR99
uppercase and lowercase codes	1812
structure	Chip
core material	FERRITE
DC Resistance	0.6 Ω
Nominal inductance(L)	1.5 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3613
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-25 °C
Package height	3.2 mm
Package length	4.5 mm
Package form	SMT
Package width	3.2 mm
method of packing	Tape
Minimum quality factor (at nominal inductance)	50
Maximum rated current	0.41 A
self resonant frequency	70 MHz
series	3613C
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	7.96 MHz
Tolerance	10%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

3613C1R5K Product Details

Live Product Chat

Inductors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3613C1R5K

(1624094-7)

T E I nternal N umber: 1 6 2 4 0 9 4 - 7

Product Highlights:

Inductor

Inductor Type = Molded Wirewound

Lead Type = Surface Mount Terminals

Wirewound

Inductance = 1.5 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

MOULDED C HIP INDUC TOR 18:12 SERIES 3613C

(PDF, English)

Catalog Pages/Data Sheets:

Moulded C hip Inductor 18:12 - Type 3613C Series - Ty...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Molded Wirewound

Element

= Wirewound

Shielded

= No

Electrical Characteristics:

Inductance (?H)

= 1.5

DC Resistance (?)

= 0.6

C urrent, Maximum (mA)

= 410

Quality Factor

= 50

Package Type

= Taped and Reeled

Tolerance (%) = 10

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3613

Packaging Style

= 1812

Package, C omponent Size

= 4.5 x 3.2

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Operation/Application:

Application

= Standard

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

3613C1R5K Related Products

	3613C1R5K	1624094-7
Description	1 ELEMENT, 1.5uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT	1 ELEMENT, 1.5uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
package instruction	1812	1812
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
uppercase and lowercase codes	1812	1812
DC Resistance	0.6 Ω	0.6 Ω
Nominal inductance(L)	1.5 µH	1.5 µH
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3613	3613
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	50	50
Maximum rated current	0.41 A	0.41 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	10%	10%
