High Power Top LED SMB850D-1100-09
Lead ( Pb ) Free Product – RoHS Compliant
SMB850D-1100-09
Specifications
1) Product Name
2) Type No.
3) Chip
(1) Chip Material
(2) Chip Dimension
(3) Chip Number
(4) Peak Wavelength
4) Package
(1) Lead Frame Die
(2)
Package Resin
(3)
Lens
High Power Top LED
SMB850D-1100-09 is an AlGaAs LED mounted on copper heat sink with a 5*5 mm package.
These devices are available to be operated and 1,400mW/sr at IFP=3A.
Outer
dimension (Unit: mm)
High Power Top LED
SMB850D-1100-09
AlGaAs
1000um*1000um
1pce
850nm typ.
Silver Plated on Copper
PPA Resin
Epoxy Resin
anode
cathode
land pattern for solder
a1 a2 a3
a1 a2 a3
heatsink
c1 c2 c3
c1 c2 c3
Absolute
Maximum Ratings [Ta=25°C]
Item
Symbol
Power Dissipation
P
D
Forward Current
I
F
Pulse Forward Current
I
FP
Reverse Voltage
V
R
Thermal Resistance
R
thja
Junction Temperature
T
j
Operating Temperature
T
OPR
Storage Temperature
T
STG
Soldering Temperature
T
SOL
Maximum Rated Value
2500
1000
3000
5
10
115
-40 ~ +100
-40 ~ +100
250
Unit
mW
mA
mA
V
K/W
°C
°C
°C
°C
‡Pulse Forward Current condition: Duty=1% and Pulse Width=10us.
‡Soldering condition: Soldering condition must be completed within 5 seconds at 250°C
Electro-Optical
Characteristics [Ta=25°C typ.]
Item
Symbol Condition Minimum
I
F
=350mA
V
F
Forward Voltage
I
F
=1000mA
V
FP
I
FP
=3A
I
F
=1000mA
470
Radiated Power
P
O
I
FP
=3A
I
F
=1000mA
Radiant Intensity
I
E
I
FP
=3A
Peak Wavelength
P
I
F
=1000mA
840
Half Width
I
F
=1000mA
long
Viewing Half Angle
I
F
100mA
short
Rise Time
tr
I
F
=1000mA
Fall Time
tf
I
F
=1000mA
‡Radiated Power is measured by S3584-08.
‡Radiant Intensity is measured by Tektronix J-6512.
Typical
1.5
2.1
3.5
630
1900
470
1400
850
37
±42
±24
25
35
Maximum
1.9
2.5
Unit
V
V
mW
mW
mW/sr
mW/sr
nm
nm
deg.
ns
ns
EPITEX INC.: 66-3 Minami-Kawabe Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel: ++81-75-682-2338
Fax: ++81-75-682-2267
e-mail : sales-dep@epitex.com
http://www.epitex.com/
epitex
10000
Opto-Device & Custom LED
High Power Top LED SMB850D-1100-09
Lead ( Pb ) Free Product – RoHS Compliant
Forward Curent - Forward Voltage
10
Relative Radiant Intensity -
Forward Current
(ta=25°C, tw=1ms, Duty=1%)
(ta=25°C, tw=1ms, Duty=1%)
Relative Radiant Intensity (A.U.)
1000mA Standard
1
Forward Current (mA)
1000
0.1
100
0.01
10
0.001
1
0.0
0.0001
0.5
1.0
1.5
2.0
2.5
3.0
1
10
100
1000
Forward Voltage (V)
Forward Current (mA)
Forward Current - Pulse Duration
10
4
9
8
7
6
5
Allowable Forward Current -
Ambient Temperature
1200
Allowable Forward Current(mA)
1100
1000
900
800
700
600
500
400
300
200
100
0
Rthja=10K/W
Forward Current Ifp [mA]
4
3
2
10
3
9
8
7
6
5
4
3
10kHz
100Hz
1kHz
10Hz
10
2
1Hz
2
10
-3
10
-2
10
-1
10
0
10
1
10
2
10
3
10
4
0
20
40
60
80
100
120
Duration tw [ms]
Ambient Temperature (°C)
EPITEX INC.: 66-3 Minami-Kawabe Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel: ++81-75-682-2338
Fax: ++81-75-682-2267
e-mail : sales-dep@epitex.com
http://www.epitex.com/
epitex
3.0
2.8
2.6
2.4
Opto-Device & Custom LED
High Power Top LED SMB850D-1100-09
Lead ( Pb ) Free Product – RoHS Compliant
Forward Voltage -
Ambient Temperture
10
Relative Radiant Intensity -
Ambient Temperature
Relative Radiant Intensity (A.U.)
9
8
7
6
5
4
3
If=1000mA
If=1000mA
Forward Voltage (V)
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
0
20
40
60
80
100
2
1
9
8
7
6
5
4
3
2
0.1
0
20
40
60
80
100
Ambient Temperatture (°C)
Ambient Temperature (°C)
Peak Wavelength -
Ambient Temperature
900
If=1000mA
890
880
870
860
850
840
830
820
810
800
0
20
40
60
80
100
Peak Wavelength (nm)
Ambient Temperature (°C)
EPITEX INC.: 66-3 Minami-Kawabe Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel: ++81-75-682-2338
Fax: ++81-75-682-2267
e-mail : sales-dep@epitex.com
http://www.epitex.com/
epitex
1.0
Opto-Device & Custom LED
High Power Top LED SMB850D-1100-09
Lead ( Pb ) Free Product – RoHS Compliant
Relative Spectral Emission
(ta=25°C)
Relative Radiant Intensity (A.U.)
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
750
800
850
900
950
Wavelength (nm)
Radiation Characteristics
1.0
Relative Radiant Intensity (A.U.)
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
long ±42
short ±24
-90
-60
-30
0
30
60
90
Angle (deg.)
EPITEX INC.: 66-3 Minami-Kawabe Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel: ++81-75-682-2338
Fax: ++81-75-682-2267
e-mail : sales-dep@epitex.com
http://www.epitex.com/
epitex
♦Wrapping
Opto-Device & Custom LED
High Power Top LED SMB850D-1100-09
Lead ( Pb ) Free Product – RoHS Compliant
Moisture barrier bag aluminum laminated film with a desiccant to keep out the moisture absorption
during the transportation and storage.
SMD LED STORAGE AND HANDLING PRECAUTIONS
＜Storage
Conditions before Opening a Moisture-Barrier Aluminum Bag＞
・
Before opening a moisture-barrier aluminum bag, please store it at <30ºC, <60%RH.
note that the maximum shelf life is 12 months under these conditions.
＜Storage
Conditions after Opening a Moisture-Barrier Aluminum Bag＞
・
After opening a moisture-barrier aluminum bag, store the aluminum bag and silica gel in a
desiccator.
・After
opening the bag, please solder the LEDs within 72 hours in a room with 5 - 30ºC, <50%RH.
・Please
put any unused, remaining LEDs and silica gel back in the same aluminum bag and then
vacuum-seal the bag.
・It
is recommended to keep the re-sealed bag in a desiccator at <30%RH.
＜Notes
about Re-sealing a Moisture-Barrier Aluminum Bag＞
・When
vacuum-sealing an opened aluminum bag, if you find the moisture-indicator of the silica gel
has changed to pink from blue (indicating a relative humidity of 30 % or more), please do not use
the unused LEDs, the aluminum bag, or the silica gel.
＜Notes
about Opening a Re-sealed Moisture-Barrier Aluminum Bag＞
・When
opening a vacuumed and re-sealed aluminum bag in order to use the remaining LEDs
stored in the bag, if you find that the moisture-indicator of the silica has changed to pink, please
do not use the LEDs.
※The
72-hour- long floor life does not include the time while LEDs are stored in the
moisture-barrier aluminum bag.
However, we strongly recommend to solder the LEDs as soon as possible after opening the
aluminum bag.
Please
