ABMM3-FREQ-18-R090-E-3-T datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> ABMM3-FREQ-18-R090-E-3-T

ABMM3-FREQ-18-R090-E-3-T: DescriptionParallel - 3Rd Overtone Quartz Crystal, 45MHz Min, 60MHz Max, ROHS COMPLIANT, CERAMIC PACKAGE-4; CategoryPassive components Crystal/resonator; File Size125KB，1 Pages; ManufacturerAbracon; Websitehttp://www.abracon.com/index.htm; Environmental Compliance

Download Datasheet Parametric View All

ABMM3-FREQ-18-R090-E-3-T Overview

Parallel - 3Rd Overtone Quartz Crystal, 45MHz Min, 60MHz Max, ROHS COMPLIANT, CERAMIC PACKAGE-4

ABMM3-FREQ-18-R090-E-3-T Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	conform to
Maker	Abracon
package instruction	ROHS COMPLIANT, CERAMIC PACKAGE-4
Reach Compliance Code	compliant
Other features	TAPE AND REEL
Ageing	5 PPM/YEAR
Crystal/Resonator Type	PARALLEL - 3RD OVERTONE
Drive level	100 µW
frequency stability	0.005%
frequency tolerance	25 ppm
load capacitance	18 pF
Manufacturer's serial number	ABMM3
Installation features	SURFACE MOUNT
Maximum operating frequency	60 MHz
Minimum operating frequency	45 MHz
Maximum operating temperature	70 °C
Minimum operating temperature
physical size	L6.0XB3.5XH1.1 (mm)/L0.236XB0.138XH0.043 (inch)
Series resistance	90 Ω
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

CERAMIC SURFACE MOUNT LOW

PROFILE MICROPROCESSOR CRYSTAL

ABMM3

FEATURES:

• Suitable for reflow; Superior heat-resistant glass sealing

• Low in height - suitable for thin equipment

• AT-strip cut offers a tight tolerance & stability

Pb in glass

(exempt per RoHS 2002/95/EC Annex (5))

RoHS

Compliant

6.0 x 3.5 x 1.1 mm

| | | | | | | | | | | | | | |

APPLICATIONS:

• Computers, Modems, Microprocessors

• Communication, Test equipment

• PCMCIA

STANDARD SPECIFICATIONS:

PARAMETERS

ABRACON P/N

Frequency Range

Operation Mode

Operating Temperature

Storage Temperature

Frequency Tolerance at 25°C

Frequency Stability over the

Operating Temp. (Ref to +25°C)

Equivalent Series Resistance

Shunt Capacitance C

Load Capacitance C

Drive Level

Aging at 25°C Per Year

Insulation Resistance

ABMM3 Series

8.0 MHz to 60.0 MHz

Fundamental 8.0 MHz - 50.0 MHz

Third-Overtone for F ~ 45.0 MHz - 60.0 MHz

- 10°C to + 60°C (see options)

- 40°C to + 90°C

± 50 ppm max. (see options)

See Table 1

7pF max.

18pF (see options)

100μW max.

± 5ppm max.

500Mohms min at 100Vdc ± 15V

TABLE 1

Frequency (MHz)

8.000 - 9.999 (Fund)

10.000 - 15.99 (Fund)

16.000 - 50.000 (Fund)

45.000 - 60.00 (3rd O/T)

ESR (Ω)

OPTIONS & PART IDENTIFICATION:

(Left blank if standard)

ABMM3 - Frequency -

Frequency

XX.XXXX MHz

-R

Packaging

Blank

Bulk

Tape & Reel

Temp. Range º

Load Capacitance

Please specify CL in pF or

S for Series

0ºC to +70ºC

-20ºC to +0ºC

-30ºC to +70ºC

-30ºC to +85ºC

-40ºC to +85ºC

ESR

RXXX (Value in

)

Freq. Tolerance

± 20 ppm

± 25 ppm

± 30 ppm

Freq. Stability

± 20 ppm

± 25 ppm

± 30 ppm

± 35 ppm

± 100 ppm

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

Revised: 07.10.07

30332 Esperanza, Rancho Santa Margarita, California 92688

tel 949-546-8000

fax 949-546-8001

| www.abracon.com

Visit www.abracon.com for Terms & Conditions of Sale
