5962-00-548-2018 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> 5962-00-548-2018

Preview

5962-00-548-2018: Description5962-00-548-2018 Amplifier basic information: 5962-00-548-2018 is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2 5962-00-548-2018 amplifier core information: The minimum operating temperature of 5962-00-548-2018 is 70 °C. Its maximum bias current at a peak reflow temperature of 22525°C is: 0.025 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-00-548-2018 is 35 V/us. The maximum slew rate of 5962-00-548-2018 given by the manufacturer is 4 mA, while the minimum slew rate is 20 V/us. Its minimum voltage gain is 70000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-00-548-2018 gain becomes 0.707 times the low-frequency gain is 100000 kHz. The nominal supply voltage of 5962-00-548-2018 is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of 5962-00-548-2018 is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions for 5962-00-548-2018: 5962-00-548-2018 has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8 5962-00-548-2018 amplifier other information: 5962-00-548-2018 adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962-00-548-2018 is: YES (AVCL>=5). Its temperature grade is: COMMERCIAL. And its humidity sensitivity level is: 1. 5962-00-548-2018 does not comply with Rohs certification. It contains lead. The corresponding JESD-30 code is: O-MBCY-W8. The material of the 5962-00-548-2018 package is mostly METAL. And its package shape is ROUND. 5962-00-548-2018 package pin formats are: CYLINDRICAL. Its terminal form is: WIRE.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size318KB，10 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Alternative parts：5962-00-548-2018

Download Datasheet Parametric Compare View All

5962-00-548-2018 Overview

5962-00-548-2018 Amplifier basic information:

5962-00-548-2018 is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CAN8,.2

5962-00-548-2018 amplifier core information:

The minimum operating temperature of 5962-00-548-2018 is 70 °C. Its maximum bias current at a peak reflow temperature of 22525°C is: 0.025 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-00-548-2018 is 35 V/us. The maximum slew rate of 5962-00-548-2018 given by the manufacturer is 4 mA, while the minimum slew rate is 20 V/us. Its minimum voltage gain is 70000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-00-548-2018 gain becomes 0.707 times the low-frequency gain is 100000 kHz.

The nominal supply voltage of 5962-00-548-2018 is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-15 V. The input offset voltage of 5962-00-548-2018 is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions for 5962-00-548-2018:

5962-00-548-2018 has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8

5962-00-548-2018 amplifier other information:

5962-00-548-2018 adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962-00-548-2018 is: YES (AVCL>=5). Its temperature grade is: COMMERCIAL. And its humidity sensitivity level is: 1.

5962-00-548-2018 does not comply with Rohs certification. It contains lead. The corresponding JESD-30 code is: O-MBCY-W8. The material of the 5962-00-548-2018 package is mostly METAL. And its package shape is ROUND.

5962-00-548-2018 package pin formats are: CYLINDRICAL. Its terminal form is: WIRE.

5962-00-548-2018 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	BCY
package instruction	, CAN8,.2
Contacts	8
Reach Compliance Code	not_compliant
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C	0.025 µA
frequency compensation	YES (AVCL>=5)
Maximum input offset voltage	7000 µV
JESD-30 code	O-MBCY-W8
low-dissonance	NO
Humidity sensitivity level	1
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	METAL
Encapsulate equivalent code	CAN8,.2
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	225
power supply	+-15 V
Certification status	Not Qualified
minimum slew rate	20 V/us
Nominal slew rate	35 V/us
Maximum slew rate	4 mA
Supply voltage upper limit	22.5 V
Nominal supply voltage (Vsup)	15 V
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal form	WIRE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	100000 kHz
Minimum voltage gain	70000
broadband	YES
Base Number Matches	1

Preview

Download Datasheet

View All

HA-2620, HA-2625

Data Sheet

January 16, 2006

FN2903.8

100MHz, High Input Impedance, Very

Wideband, Uncompensated Operational

Amplifiers

HA-2620/2625 are bipolar operational amplifiers that feature

very high input impedance (500MΩ, HA-2620) coupled with

wideband AC performance. The high resistance of the input

stage is complemented by low offset voltage (0.5mV,

HA-2620) and low bias and offset current (1nA, HA-2620) to

facilitate accurate signal processing. Input offset can be

reduced further by means of an external nulling

potentiometer. The 100MHz gain bandwidth product

(HA-2620/2625 are stable for closed loop gains greater than

5), 35V/µs slew rate and 150kV/V open loop gain enables

HA-2620/2625 to perform high gain amplification of very fast,

wideband signals. These dynamic characteristics, coupled

with fast settling times, make these amplifiers ideally suited

to pulse amplification designs as well as high frequency

(e.g., video) applications. The frequency response of the

amplifier can be tailored to exact design requirements by

means of an external bandwidth control capacitor connected

from the Comp pin to GND.

In addition to its application in pulse and video amplifier

designs, HA-2620/2625 is particularly suited to other high

performance designs such as high-gain low distortion audio

amplifiers, high-Q and wideband active filters and high-

speed comparators. For more information, please refer to

Application Notes AN509, AN519 and AN546.

Features

• Gain Bandwidth Product (A

≥

5). . . . . . . . . . . . . 100MHz

• High Input Impedance . . . . . . . . . . . . . . . . . . . . . 300MΩ

• Low Input Bias Current. . . . . . . . . . . . . . . . . . . . . . . . 5nA

• Low Input Offset Current . . . . . . . . . . . . . . . . . . . . . . 5nA

• Low Input Offset Voltage . . . . . . . . . . . . . . . . . . . . . . 3mV

• High Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150kV/V

• Slew Rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35V/µs

• Output Short Circuit Protection

• Compensation Pin for Unity Gain Capability

Applications

• Video and RF Amplifier

• Pulse Amplifier

• Audio Amplifiers and Filters

• High-Q Active Filters

• High Speed Comparators

• Low Distortion Oscillator

Pinouts

HA-2625 (PDIP, SOIC)

TOP VIEW

Ordering Information

PART

NUMBER

HA2-2620-2

HA3-2625-5

HA9P2625-9

PART

MARKING

HA2-2620-2

HA3-2625-5

26259

TEMP.

RANGE

(

PKG.

DWG. #

BAL

-IN

+IN

V-

COMP

V+

OUT

BAL

PACKAGE

-55 to 125 8 Pin Metal Can T8.C

0 to 75

-40 to 85

8 Ld PDIP

8 Ld SOIC

E8.3

M8.15

HA-2620 (METAL CAN)

TOP VIEW

COMP

BAL 1

-IN

V-

V+

6 OUT

+IN

5 BAL

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or

1-888-468-3774

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

5962-00-548-2018 Related Products

	5962-00-548-2018	5962-01-103-6124	5962-00-434-2816
Description	IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL	IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL	IC,OP-AMP,SINGLE,BIPOLAR,CAN,8PIN,METAL
Is it lead-free?	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	BCY	BCY	BCY
package instruction	, CAN8,.2	, CAN8,.2	, CAN8,.2
Contacts	8	8	8
Reach Compliance Code	not_compliant	not_compliant	_compli
ECCN code	EAR99	EAR99	EAR99
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C	0.025 µA	0.025 µA	0.015 µA
frequency compensation	YES (AVCL>=5)	YES (AVCL>=5)	YES (AVCL>=5)
Maximum input offset voltage	7000 µV	7000 µV	6000 µV
JESD-30 code	O-MBCY-W8	O-MBCY-W8	O-MBCY-W8
low-dissonance	NO	NO	NO
Humidity sensitivity level	1	1	1
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V
Number of functions	1	1	1
Number of terminals	8	8	8
Maximum operating temperature	70 °C	70 °C	125 °C
Package body material	METAL	METAL	METAL
Encapsulate equivalent code	CAN8,.2	CAN8,.2	CAN8,.2
Package shape	ROUND	ROUND	ROUND
Package form	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL
Peak Reflow Temperature (Celsius)	225	225	225
power supply	+-15 V	+-15 V	+-15 V
Certification status	Not Qualified	Not Qualified	Not Qualified
minimum slew rate	20 V/us	20 V/us	25 V/us
Nominal slew rate	35 V/us	35 V/us	35 V/us
Maximum slew rate	4 mA	4 mA	3.7 mA
Supply voltage upper limit	22.5 V	22.5 V	22.5 V
Nominal supply voltage (Vsup)	15 V	15 V	15 V
technology	BIPOLAR	BIPOLAR	BIPOLAR
Temperature level	COMMERCIAL	COMMERCIAL	MILITARY
Terminal form	WIRE	WIRE	WIRE
Terminal location	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	100000 kHz	100000 kHz	100000 kHz
Minimum voltage gain	70000	70000	70000
broadband	YES	YES	YES
