D Subminiature
Coaxial 90° – European footprint, sizes DE – DC, with metal bracket
75 Ohm part numbers with metal bracket
and captive nut M3
Shell Layout
size
P/N without pushfit
P/N with pushfit
Combo D
®
/European Version
75 Ohm part numbers with metal bracket
with bushing dia. 3,05
P/N without pushfit
P/N with pushfit
75 Ohm part numbers with metal bracket
with post M3
P/N without pushfit
P/N with pushfit
DE
DA
DA
DA
DA
DB
DB
DB
DB
DB
DC
DC
DC
DC
DC
DC
5W1
7W2
11W1
3W3
3WK3
5W5
9W4
13W3
17W2
21W1
8W8
13W6
17W5
21WA4
25W3
27W2
DEM-5C1P-1A9N-A191-K87
DAM-7C2P-1A9N-A191-K87
DAM-11C1P-1A9N-A191-K87
DAM-3C3P-1A9N-A191-K87
DAM-3CK3P-1A9N-A191-K87
DBM-5C5P-1A9N-A191-K87
DBM-9C4P-1A9N-A191-K87
DBM-13C3P-1A9N-A191-K87
DBM-17C2P-1A9N-A191-K87
DBM-21C1P-1A9N-A191-K87
DCM-8C8P-1A9N-A191-K87
DCM-13C6P-1A9N-A191-K87
DCM-17C5P-1A9N-A191-K87
DCM-21CA4P-1A9N-A191-K87
DCM-25C3P-1A9N-A191-K87
DCM-27C2P-1A9N-A191-K87
DEM-5C1P-1A9N-A191-K87-146
DAM-7C2P-1A9N-A191-K87-146
DAM-11C1P-1A9N-A191-K87-146
DAM-3C3P-1A9N-A191-K87-146
DAM-3CK3P-1A9N-A191-K87-146
DBM-5C5P-1A9N-A191-K87-146
DBM-9C4P-1A9N-A191-K87-146
DBM-13C3P-1A9N-A191-K87-146
DBM-17C2P-1A9N-A191-K87-146
DBM-21C1P-1A9N-A191-K87-146
DCM-8C8P-1A9N-A191-K87-146
DCM-13C6P-1A9N-A191-K87-146
DCM-17C5P-1A9N-A191-K87-146
DCM-21CA4P-1A9N-A191-K87-146
DCM-25C3P-1A9N-A191-K87-146
DCM-27C2P-1A9N-A191-K87-146
DEM-5C1P-1AFN-A191-K87
DAM-7C2P-1AFN-A191-K87
DAM-11C1P-1AFN-A191-K87
DAM-3C3P-1AFN-A191-K87
DAM-3CK3P-1AFN-A191-K87
DBM-5C5P-1AFN-A191-K87
DBM-9C4P-1AFN-A191-K87
DBM-13C3P-1AFN-A191-K87
DBM-17C2P-1AFN-A191-K87
DBM-21C1P-1AFN-A191-K87
DCM-8C8P-1AFN-A191-K87
DCM-13C6P-1AFN-A191-K87
DCM-17C5P-1AFN-A191-K87
DCM-21CA4P-1AFN-A191-K87
DCM-25C3P-1AFN-A191-K87
DCM-27C2P-1AFN-A191-K87
DEM-5C1P-1AFN-A191-K87-146
DAM-7C2P-1AFN-A191-K87-146
DAM-11C1P-1AFN-A191-K87-146
DAM-3C3P-1AFN-A191-K87-146
DAM-3CK3P-1AFN-A191-K87-146
DBM-5C5P-1AFN-A191-K87-146
DBM-9C4P-1AFN-A191-K87-146
DBM-13C3P-1AFN-A191-K87-146
DBM-17C2P-1AFN-A191-K87-146
DBM-21C1P-1AFN-A191-K87-146
DCM-8C8P-1AFN-A191-K87-146
DCM-13C6P-1AFN-A191-K87-146
DCM-17C5P-1AFN-A191-K87-146
DCM-21CA4P-1AFN-A191-K87-146
DCM-25C3P-1AFN-A191-K87-146
DCM-27C2P-1AFN-A191-K87-146
DEM-5C1P-1AHN-A191-K87
DAM-7C2P-1AHN-A191-K87
DAM-11C1P-1AHN-A191-K87
DAM-3C3P-1AHN-A191-K87
DAM-3CK3P-1AHN-A191-K87
DBM-5C5P-1AHN-A191-K87
DBM-9C4P-1AHN-A191-K87
DBM-13C3P-1AHN-A191-K87
DBM-17C2P-1AHN-A191-K87
DBM-21C1P-1AHN-A191-K87
DCM-8C8P-1AHN-A191-K87
DCM-13C6P-1AHN-A191-K87
DCM-17C5P-1AHN-A191-K87
DCM-21CA4P-1AHN-A191-K87
DCM-25C3P-1AHN-A191-K87
DCM-27C2P-1AHN-A191-K87
DEM-5C1P-1AHN-A191-K87-146
DAM-7C2P-1AHN-A191-K87-146
DAM-11C1P-1AHN-A191-K87-146
DAM-3C3P-1AHN-A191-K87-146
DAM-3CK3P-1AHN-A191-K87-146
DBM-5C5P-1AHN-A191-K87-146
DBM-9C4P-1AHN-A191-K87-146
DBM-13C3P-1AHN-A191-K87-146
DBM-17C2P-1AHN-A191-K87-146
DBM-21C1P-1AHN-A191-K87-146
DCM-8C8P-1AHN-A191-K87-146
DCM-13C6P-1AHN-A191-K87-146
DCM-17C5P-1AHN-A191-K87-146
DCM-21CA4P-1AHN-A191-K87-146
DCM-25C3P-1AHN-A191-K87-146
DCM-27C2P-1AHN-A191-K87-146
For performance class 1 replace A191 with A190.
For performance class 3 delete A191.
For 50 ohm coaxial replace C with X, Example:
DCM-13C6P-1AFN-A191-K87-146 becomes
DCM-13X6P-1AFN-A191-K87-146.
For pushfit 90° pcb hole diameter 3,2 mm replace 146
with 162. For captive nut 4-40UNC replace 1A9N with
1A7N and 1AHN with 1A8N.
Pin
A
C
B
2,54
3,7
±0,3
7,3
±0,15
A1
1
2
A2
7W25
3
ITT
4
5
CANNON
0,6
10
°
q
q
q
q
q
Dimensions
Shell
size
A
±
0,38
30,8
39,15
53,05
69,3
B
±
0,13
C
±
0,13
D
±
0,13
E
±
0,13
F
±
0,25
L
+
0,2
W
±
0,4
DE
DA
DB
DC
16,9
25,25
38,95
55,4
25
33,3
47,05
63,5
8,35
8,35
8,35
8,35
12,55
12,55
12,55
12,55
10,7
10,7
10,8
10,8
0,8
0,8
0,9
0,9
6,7
6,7
6,8
6,8
4
Dimensions are mm
Subject to change
W
L
F
For contact cavity arrangements, see page 52.
For pcb hole pattern, see page 54 – 56.
For mounting methods, see page 86 – 87.
For panel cut-outs, see our D Subminiature
catalogue.
For contact arrangements in shell size DD
please refer to our D Subminiature catalogue.
11,7
±0,2
14,9
±0,2
Ø 0,6
D
E
