ISL6527IBZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> ISL6527IBZ

ISL6527IBZ: DescriptionSWITCHING CONTROLLER, 340 kHz SWITCHING FREQ-MAX, PDSO14, ROHS COMPLIANT, PLASTIC, MS-012AB, SOIC-14; CategoryPower/power management The power supply circuit; File Size1011KB，17 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ISL6527IBZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ISL6527IBZ	-	-	View	Buy Now

ISL6527IBZ Overview

SWITCHING CONTROLLER, 340 kHz SWITCHING FREQ-MAX, PDSO14, ROHS COMPLIANT, PLASTIC, MS-012AB, SOIC-14

ISL6527IBZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOP,
Contacts	14
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	3.63 V
Minimum input voltage	2.97 V
Nominal input voltage	3.3 V
JESD-30 code	R-PDSO-G14
JESD-609 code	e3
length	8.65 mm
Humidity sensitivity level	3
Number of functions	1
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	PUSH-PULL
Maximum switching frequency	340 kHz
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	3.9 mm
Base Number Matches	1
