3-1437264-3: Description72 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT; CategoryThe connector The connector; File Size120KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

3-1437264-3 Overview

72 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT

3-1437264-3 Parametric

Parameter Name	Attribute value
Objectid	1643006499
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	3.96 mm
Termination type	SOLDER
Total number of contacts	72
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

< .050" C enterline

Product Feature Selector

> Product Details

C6D36DS29C3 Product Details

Live Product Chat

.100, .125, .156 Centerline Cantilever Connectors

Always EU R oHS com plia nt but not ELV C om plia nt

(

Sta te m e nt of

C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

C6D36DS29C3

(3-1437264-3)

T E I nternal N umber: 3 - 1 4 3 7 2 6 4 - 3

Product Highlights:

C onnector

C onnector Type = C ard Edge

3.96 mm C enterline

Row-to-Row Spacing = 5.08 mm

36 Dual Positions

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

card edge connectors

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

C onnector Type = C ard Edge

Number of Dual Positions

= 36

Mounting Ears

= Without

PC B Retention Feature

= No

PC B Mount Angle = Vertical

Post Type = Solder

Termination Related Features:

Termination Post Length (mm [in])

= 4.06 [0.160]

Body Related Features:

C enterline (mm [in])

= 3.96 [0.156]

Row-to-Row Spacing (mm [in])

= 5.08 [0.200]

C ard Slot Depth (mm [in])

= 7.62 [0.300]

Contact Related Features:

C ontact Base Material = High Strength C opper Alloy

C ontact Plating, Mating Area, Material = Gold (30)

Housing Related Features:

Housing Material = Thermoplastic - GF

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= RoHS/Not ELV C ompliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS not ELV

compliant

Other:

Brand = Tyco Electronics

Additional Information:

Product Line Information

3-1437264-3 Related Products

	3-1437264-3	C6D36DS29C3
Description	72 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT	72 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
Connector type	CARD EDGE CONNECTOR	CARD EDGE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE
Contact material	NOT SPECIFIED	NOT SPECIFIED
DIN compliance	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
MIL compliance	NO	NO
Mixed contacts	NO	NO
Installation method	STRAIGHT	STRAIGHT
Installation type	BOARD	BOARD
Number of rows loaded	2	2
Options	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	3.96 mm	3.96 mm
Termination type	SOLDER	SOLDER
Total number of contacts	72	72
UL Flammability Code	94V-0	94V-0
