DESCRIPTION
2
REVISIONS
1
DATE
8/25/09
APPROVED
D.FRISIELLO
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
ECN 4210: UP-DATED DIMENSIONS PER SUPPLIER
D
1.39 35.4
D
1/4-20 UNC
.38 HEX
1.13 28.7
C
.75 19.2
.25 6.4
.19 4.7
C
B
NOTES:
MATERIAL:
BODY: BRASS
FERRULE: BRASS OR COPPER ALLOY
SLEEVE: ACETAL
INSULATOR: ACETAL
FINISH:
BODY: NICKEL PLATE
FERRULE: NICKEL PLATE
PIN: GOLD PLATE
ELECTRICAL:
IMPEDANCE: 75 OHM
BRAID
RECOMMENDED
CABLE STRIPPING
DIMENSIONS
CENTER CONDUCTOR
DIELECTRIC
B
RoHS Compliant
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES [mm]
DIMENSIONAL TOLERANCES:
.X = ±.1
.XX = ±.02
.XXX = ±.005
ANGULAR TOLERANCES:
ALL = ± 1°
PROJECTION
APPROVALS
DRAWN BY
DATE
11/06/01
11/06/01
11/06/01
PRODUCT DESCRIPTION
CATEGORY
MCCORMICK
CHECKED BY
A
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
PACKAGING:
INDIVIDUALLY PACKAGE EACH ASSEMBLY UTILIZING APPROPRIATE SIZED BAG
APPLICATION:
RG59 & RG62 COAX CABLE ASSEMBLIES
D.PARHAM
APPROVED BY
R.CARRICK
COAXIAL
CONN BNC M RA RG59/62 TWIST ON
SIZE
A
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
MAY VARY
COLOR VARIATIONS
MAY OCCUR
REF
A
43321
2
FSCM NO.
DWG. NO.
BAC985
1
REV.
SHEET 1 OF 1
SCALE: NONE
CAD FILE:
BAC985.SLDDRW
E
8
7
6
5
4
3
