32S12C-FC

Description
Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, GREEN, PLASTIC, SMD, 4 PIN
CategoryPassive components    Crystal/resonator
File Size337KB,2 Pages
ManufacturerPericom Semiconductor Corporation (Diodes Incorporated)
Websitehttps://www.diodes.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

32S12C-FC Overview

Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, GREEN, PLASTIC, SMD, 4 PIN

32S12C-FC Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionGREEN, PLASTIC, SMD, 4 PIN
Reach Compliance Codecompliant
Other featuresTAPE AND REEL
Ageing5 PPM/FIRST YEAR
Crystal/Resonator TypePARALLEL - FUNDAMENTAL
Drive level0.1 µW
frequency stability0.0042%
frequency tolerance20 ppm
load capacitance12.5 pF
Manufacturer's serial number32S12
Installation featuresSURFACE MOUNT
Nominal operating frequency0.032768 MHz
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
physical sizeL8.7XB3.25XH2.5 (mm)/L0.343XB0.128XH0.098 (inch)
Series resistance50000 Ω
surface mountYES
Base Number Matches1
32S12 Series
Tuning Fork Quartz Crystal
32.768 kHz Plastic SMD
Actual Size
Product Description
The 32S12 Series is a 32.768 kHz tuning fork-type
quartz crystal mounted in a plastic-molded package.
Electrical Characteristics:
Nominal Frequency ...............................
Frequency Tolerance at 25°C...................
Turnover Temperature, T
0
.......................
Temperature Coefficient, K .....................
Load Capacitance, C
L
...........................
Equivalent Series Resistance, R
S
...............
Shunt Capacitance, C
0
...........................
Recommended Drive Level, Pd.................
Maximum Drive Level, Pd
MAX
...................
Aging, ∆ F / f (1st year @ 25°C ±3°C) ....
Operating Temperature Range.................
Storage Temperature Range ....................
32.768 kHz
±20ppm
+25°C ±5°C
(–3.5 ±0.8) x 10
–8
/°C
2
12.5pF standard
50 k-ohm Max.
1.0pF, typical
0.1µW
1µW Max.
±5ppm Max.
–40 to +85°C
–55 to +125°C
Product Features
• Rugged, plastic-molded design, resistant to shock
and vibration
• Excellent resistance to heat shock and
environmental characteristics
• Ideally suited for automated pick-and-place
assembly environments
• Available on tape and reel
• Pb-free and RoHS/Green compliant
• Time of day clocks
• Reference for microprocessor's low power/stondby
mode
Typical Applications
Environmental / Process Specifications
High Temperature Storage:
Low Temperature Storage:
Thermal Shock:
Shock:
Resistance to Soldering Heat:
Solderability:
Terminal Strength:
Less than ±5 ppm change after
500H at 80°C
Less than ±5 ppm change after
500H at –30°C
Less than ±5 ppm change at 25°C
after –25 to +80°C 20 cycles each
1H
MIL-STD-883, Method 2002,
Condition B
J-STD-020C, Table 5-2, Pb-free
devices (2 cycles max)
JESD22-B102-D, Method 2
(Preconditioning E)
Will withstand pull weight of 500
grams, 30 seconds maximum
Reflow Temperature:
260°C Max (RoHS Compliant version only)
Pericom Semiconductor Corporation • 1-800-435-2336 • http://www.pericom.com/saronix
1
All specifications are subject to change without notice.
DS-107 Rev G | 03/20/2006
