4275X502K

Description
RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 5000ohm, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size114KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

4275X502K Overview

RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 5000ohm, ROHS COMPLIANT

4275X502K Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1666348317
package instruction,
Reach Compliance Codeunknown
ECCN codeEAR99
YTEOL0
Actuator directionHORIZONTAL
Actuator typeSCREW
Manufacturer's serial number4275
Installation featuresTHROUGH HOLE MOUNT
Number of terminals3
number of turns1
Package shapeRECTANGULAR PACKAGE
Rated power dissipation(P)0.5 W
resistance5000 Ω
resistance lawLINEAR
Resistor typeTRIMMER
surface mountNO
technologyCERMET
Terminal surfaceNOT SPECIFIED
Terminal shapeWIRE
Tolerance10%

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Resistors
>
Product Feature Selector
> Product Details
4275X502K Product Details
Live Product Chat
Variable Resistors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
4275X502K
(1623902-9)
T E I nternal N umber: 1 6 2 3 9 0 2 - 9
Product Highlights:
l
Variable Resistor
l
Resistor Type = Trimmer
l
Resistance Selection = K ?
l
Resistance = 5K ?
l
Power Rating = .50 W
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
Professional Trimmers - Type 4275 Series - Tyco Elec...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Variable Resistor
l
Resistor Type
= Trimmer
l
Resistance (?)
= 5K
l
Element
= C ermet
l
Sealed
= Yes
l
Termination Type
= PC B Terminations
Electrical Characteristics:
l
Resistance Selection (?) = K
l
Power Rating (W)
= 0.50
l
Tolerance (%)
= 10
Termination Related Features:
l
Termination Post Orientation
= 5.0 x 2.5
Body Related Features:
l
Series
= 4275
l
Package, C omponent Size
= 6
Configuration Related Features:
l
Sections
= Single
l
Adjustment Location
= Side
l
Adjustment Style
= C ross Slot
l
Operating Function
= Single Turn
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Conditions for Usage:
l
Temperature C oefficient (ppm/?C )
= 100
Other:
l
Brand = C itec
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

4275X502K Related Products

4275X502K 1623902-9
Description RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 5000ohm, ROHS COMPLIANT RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 5000ohm, ROHS COMPLIANT
Is it Rohs certified? conform to conform to
Objectid 1666348317 1666347480
Reach Compliance Code unknown unknown
ECCN code EAR99 EAR99
Actuator direction HORIZONTAL HORIZONTAL
Actuator type SCREW SCREW
Manufacturer's serial number 4275 4275
Installation features THROUGH HOLE MOUNT THROUGH HOLE MOUNT
Number of terminals 3 3
number of turns 1 1
Package shape RECTANGULAR PACKAGE RECTANGULAR PACKAGE
Rated power dissipation(P) 0.5 W 0.5 W
resistance 5000 Ω 5000 Ω
resistance law LINEAR LINEAR
Resistor type TRIMMER TRIMMER
surface mount NO NO
technology CERMET CERMET
Terminal surface NOT SPECIFIED NOT SPECIFIED
Terminal shape WIRE WIRE
Tolerance 10% 10%
