HUFA76423D3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> HUFA76423D3

HUFA76423D3: Description20A, 60V, 0.037 Ohm, N-Channel, Logic Level UltraFET Power MOSFETs; CategoryDiscrete semiconductor The transistor; File Size198KB，10 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

HUFA76423D3 Overview

20A, 60V, 0.037 Ohm, N-Channel, Logic Level UltraFET Power MOSFETs

HUFA76423D3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Fairchild
package instruction	IN-LINE, R-PSIP-T3
Reach Compliance Code	_compli
ECCN code	EAR99
Shell connection	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	60 V
Maximum drain current (Abs) (ID)	20 A
Maximum drain current (ID)	20 A
Maximum drain-source on-resistance	0.04 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-251AA
JESD-30 code	R-PSIP-T3
JESD-609 code	e3
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	175 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	85 W
Certification status	Not Qualified
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

HUFA76423D3, HUFA76423D3S

Data Sheet

December 2001

20A, 60V, 0.037 Ohm, N-Channel, Logic

Level UltraFET® Power MOSFETs

Packaging

JEDEC TO-251AA

JEDEC TO-252AA

Features

• Ultra Low On-Resistance

- r

DS(ON)

= 0.032Ω,

10V

- r

DS(ON)

= 0.037Ω,

• Simulation Models

- Temperature Compensated PSPICE® and SABER™

Electrical Models

- Spice and SABER Thermal Impedance Models

- www.fairchildsemi.com

• Peak Current vs Pulse Width Curve

• UIS Rating Curve

DRAIN

(FLANGE)

SOURCE

DRAIN

GATE

SOURCE

DRAIN

(FLANGE)

HUFA76423D3

HUFA76423D3S

Symbol

• Switching Time vs R

Curves

Ordering Information

PART NUMBER

PACKAGE

TO-251AA

TO-252AA

BRAND

76423D

HUFA76423D3

HUFA76423D3S

NOTE: When ordering, use the entire part number. Add the suffix T

to obtain the variant in tape and reel, e.g., HUFA76423D3ST.

= 25

C, Unless Otherwise Specified

HUFA76423D3,

HUFA76423D3S

±16

Figure 4

Figures 6, 17, 18

0.567

-55 to 175

300

260

UNITS

Absolute Maximum Ratings

Drain to Source Voltage (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

DSS

Drain to Gate Voltage (R

= 20kΩ) (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

DGR

Gate to Source Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

Drain Current

Continuous (T

= 25

C, V

= 5V) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

Continuous (T

= 25

C, V

= 10V) (Figure 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

Continuous (T

= 100

C, V

= 5V) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

Continuous (T

= 100

C, V

= 4.5V) (Figure 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

Pulsed Drain Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I

Pulsed Avalanche Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UIS

Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P

Derate Above 25

C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operating and StorageTemperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

, T

STG

Maximum Temperature for Soldering

Leads at 0.063in (1.6mm) from Case for 10s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

Package Body for 10s, See Techbrief TB334 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T

pkg

NOTES:

1. T

= 25

C to 150

CAUTION:

Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the

device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

This product has been designed to meet the extreme test conditions and environment demanded by the automotive industry. For a copy

of the requirements, see AEC Q101 at: http://www.aecouncil.com/

Reliability data can be found at: http://www.fairchildsemi.com/products/discrete/reliability/index.html.

All Fairchild semiconductor products are manufactured, assembled and tested under ISO9000 and QS9000 quality systems certification.

HUFA76423D3, HUFA76423D3S Rev. B

HUFA76423D3 Related Products

	HUFA76423D3	HUFA76423D3S
Description	20A, 60V, 0.037 Ohm, N-Channel, Logic Level UltraFET Power MOSFETs	20A, 60V, 0.037 Ohm, N-Channel, Logic Level UltraFET Power MOSFETs
Is it Rohs certified?	conform to	conform to
Maker	Fairchild	Fairchild
package instruction	IN-LINE, R-PSIP-T3	SMALL OUTLINE, R-PSSO-G2
Reach Compliance Code	_compli	_compli
ECCN code	EAR99	EAR99
Shell connection	DRAIN	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	60 V	60 V
Maximum drain current (Abs) (ID)	20 A	20 A
Maximum drain current (ID)	20 A	20 A
Maximum drain-source on-resistance	0.04 Ω	0.04 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-251AA	TO-252AA
JESD-30 code	R-PSIP-T3	R-PSSO-G2
JESD-609 code	e3	e3
Number of components	1	1
Number of terminals	3	2
Operating mode	ENHANCEMENT MODE	ENHANCEMENT MODE
Maximum operating temperature	175 °C	175 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Polarity/channel type	N-CHANNEL	N-CHANNEL
Maximum power dissipation(Abs)	85 W	85 W
Certification status	Not Qualified	Not Qualified
surface mount	NO	YES
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	THROUGH-HOLE	GULL WING
Terminal location	SINGLE	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
transistor applications	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON
