ADC150

Programmable

Integrating A/D Converter

THALER CORPORATION • 2015 N. FORBES BOULEVARD • TUCSON, AZ. 85745 • (520) 882-4000

FEATURES

•

24 BIT RESOLUTION

•

SOFTWARE SELECTABLE FEATURES

•

0.5ppm/°C MAX. SCALE FACTOR ERROR

•

2 ppm MAX. LINEARITY ERROR

APPLICATIONS

•

TEST EQUIPMENT

•

DATA ACQUISITION

•

SCIENTIFIC INSTRUMENTS

•

MEDICAL INSTRUMENTS

•

AUTO ZERO

•

SEISMOLOGICAL EQUIPMENT

•

BUS COMPATIBLE

•

INTERNAL CLOCK and REFERENCE

•

LOW POWER CONSUMPTION (0.450 WATTS)

•

ROBOTIC SYSTEMS

•

WEIGHING SYSTEMS

DESCRIPTION

ADC150 is a high performance programmable 24-

bit integrating A/D converter based on a patented

architecture. The integration time and resolution

along with the power line cycle selection can be

easily programmed through the Mode Control

Byte.

Type

ADC150C

ADC150CA

ADC150M

Temperature

Operating Range

-25°C to +85°C

-55°C to +125°C

Max. Scale

Factor Deviation

60ppm

30ppm

100ppm

ADC150 offers 2 ppm max. linearity error and

1 ppm/°C max. scale factor error over the military temperature range. It also has excellent offset stability at

2 ppm max. which the user can auto zero if desired.

ADC150's compatibility with popular microcomputer buses increases its ease of application in smart

systems. An on-board microprocessor controls all internal functions of the ADC150. Thaler designers

have minimized external connections to greatly reduce the problem often encountered when applying

ADC's.

Operating from ±15VDC and a +5VDC power supply, ADC150 is packaged in a hermetically sealed 40-pin

ceramic DIP package. Precision test equipment, scientific and medical instruments, and data acquisition

systems are primary application areas for the unusually high resolution and accuracy of this ADC.

ADC150DS REV. F MAR 00
