32164R: DescriptionSMPS Transformer, 3W; CategoryPower management transformer; File Size214KB，1 Pages; ManufacturerWurth Elektronik

Download Datasheet Parametric Compare View All

32164R Overview

SMPS Transformer, 3W

32164R Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Wurth Elektronik
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	BREADTH & HEIGHT DIM INCLUDE TERMINAL ALSO
high	8.89 mm
Maximum input voltage	57 V
Minimum input voltage	33 V
length	10.8 mm
Manufacturer's serial number	32164R
Installation features	SURFACE MOUNT
Number of primary windings	2
Number of secondary windings	1
Maximum operating frequency	200 kHz
Output voltage 1	5 V
physical size	L10.8XB13.35XH8.89 (mm)
rated power	3 W
Primary inductance	500 µH
surface mount	YES
Transformer type	SMPS TRANSFORMER
width	13.35 mm
Base Number Matches	1

Preview

Download Datasheet

View All

more than you expect

Power over Ethernet

Flyback Transformers

SwitchmodePower

EP7 SMD L-Lead

Features

•

Optimized for PoE applications

Small size

Cost effective

Low Resistance

Flat top for pick and place

Custom designs available

1500VAC Isolation

EP7 SMD Gull-wing

EP10 SMD

EP13 SMD

Part Number

32163R

32165R

32167R

32162R

32164R

32166R

750310027

32168R

32170R

32171R

32172R

32173R

32395R

V

PRI

(Volts)

33-57

9-50

33-57

13-59

V

SEC

(Volts)

3.3

5

12

3.3

5

12

3.3

12

3.3

5

12

3.3/5

P

SEC

L

PRI

L

LKG

Turns Ratio

(Watts) (µH) (µH) (PRI:AUX:SEC)

3

500 7.5

12:2.5:1

3

500 7.5

8:1.67:1

3

521 7.5

4.9:1:1.4

3

500 7.5

12:2.5:1

3

500 7.5

8:1.67:1

3

521 7.5

4.9:1:1.4

10

20.4 1.5

3.5:1.4:1

7

253 7.5

4.5:2.5:1

7

264 7.5

12:2.5:1

13.5

127 7.5

12:2.5:1

13.5

127 7.5

8:1.67:1

13.5

127 7.5

4.8:1:1.4

13.1

37 5.0 5.25:2.75:1.5:1

Package

EP7 SMD L-Lead

EP7 SMD Gull-Wing

EP10 SMD

EP13 SMD

Schematic

1

2

3

Schematic 1

Schematic 2

Schematic 3

28-Sep-07

1/1

Wurth Electronics Midcom, Inc.

121 Airport Drive—PO Box 1330

Watertown, SD 57201

T: 605.886.4385 ~ 605.886.4486

www.we-online.com ~ email: sales@midcom-inc.com
