205 Crawford St. Leominster, MA 01453 (978)534-5776 Fax(978)537-4246, www.omnirel.com
OM9402SP
GATE DRIVER
For Driving IGBT Modules
600V and 1200V, 150A to 600A
FEATURES
•
•
•
•
Rugged High Density Industrial Package
Built in Short Circuit Protection with Fault Output
High CMRR Optocoupler
CMOS/TTL Compatible Input Interface
DESCRIPTION
This series of gate drivers are ideally suited for driving the CERMOD
TM
family of
IGBT Power Modules, where small size, high performance and high reliability are
required. Designed specifically for high power motor controls, inverters, switching
power supplies, choppers and high energy pulse circuits in the aerospace, defense,
transportation, industrial and medical equipment industries.
ABSOLUTE MAXIMUM RATINGS (Tc=25°c unless otherwise noted)
Characteristic
Operating Temperature
Peak Output Current
Logic Input Voltage
Gate Positive Supply Voltage
Gate Negative Supply Voltage
Fault Output current
Isolation Voltage
Symbol
T
A
I
O(PEAK)
V
CC
+V
G
-V
G
I
FLT
Vis
Min.
-40
-
-
-14
-
Typ.
-
-
5
15
-
-
Max.
100
8
5.25
16
-0.5
8
2500
UNIT
°C
A
V
V
V
mA
VAC
1min
06/22/98
Rev.01
205 Crawford St. Leominster, MA 01453 (978)534-5776 Fax(978)537-4246, www.omnirel.com
ELECTRICAL CHARACTERISTICS:
Parameter
OM9402SP (Tc= 25°C unless otherwise specified)
°
Test Condition
Min.
Typ.
Max
Unit
SWITCHING CHARACTERISTICS
t
PLH
Signal to High Level Output
Propagation Delay Time
t
PHL
Signal to Low Level Output
Propagation Delay Time
(t
PHL
-t
PLH
) Propagation Delay Difference
Between Any Two Parts
tr Rise Time
tf Fall Time
I CM I Output Common Mode Transient
Immunity
V
C
Desat. (Collector) Threshold
V
SIG
Logic Low Signal Voltage
V
SIG
Logic High Signal Voltage
I
SIG
Logic Low Current
V
UVLO+
UVLO Threshold Positive
V
UVLO-
UVLO Threshold Negative
0.15
R
G
=2.5Ω,
C
G=
2200pF
f
PWM
=10kHz
Duty=50%
0.15
-0.4
0.30
0.32
0.4
0.15
0.15
25
7.0
0.55
0.55
µS
µS
µS
µS
µS
kV/µS
V
CM
=1500V
15
6.5
2.0
-0.5
11.5
7.5
0.8
V
IN
=0.4V
V
OUT
>5V
V
OUT
<5V
-0.4
13.0
11.8
13.6
12.4
V
V
V
mA
V
V
SUPPLY VOLTAGES
V
CC
Logic Input Voltage (Recommended)
+V
G
Gate Positive Supply Voltage (Recommended)
-V
G
Gate Negative Supply Voltage(Recommended)
4.75
14.5
-10
5
15
5.25
-8
V
V
V
R
G
- specified in the IGBT module data sheet
06/22/98
Rev.01
