Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
A(mm)
11.76
16.84
21.92
27.00
32.08
37.16
42.24
47.32
52.40
57.48
62.56
67.64
72.72
Dimensions
A(inch)
Poles
0.463
15
0.663
16
0.863
17
1.063
18
1.263
19
1.463
20
1.663
21
1.863
22
2.063
23
2.263
24
2.463
2.663
2.863
A(mm)
77.80
82.88
87.96
93.04
96.12
103.20
108.28
113.36
118.44
123.52
A(inch)
3.063
3.263
3.463
3.663
3.863
4.063
4.263
4.463
4.663
4.863
SPECIFICATIONS
Current Rating:
Contact Material:
Insulation Material:
Insulation Resistance:
Withstanding:
Operating Temp:
16Amp AC300V
Brass, Tin Plated
Polyamide 66(UL94V-0), Black
2000MΩ min
AC2000V min
-40ºC to +105ºC
A
B
C
D
D
E
E
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Series
Style
Pitch
CMTB
ME030K
XXX
Terminal Block Right Angle closed 381=1.81mm
end plug-able
250=3/50mm
500=5.00mm
508=5.08mm
Date
03/02/01
03/02/01
03/02/01 Part No.:
Positions
XX
02-24
Color
GN
GN=Green
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CMTB-ME030K-508-XX-GN
G
7
8
9
G
0.00 ± 0.20 Angles ± 3°
UNIT: mm
5
6
Description: Right Angle closed end plug-able terminal block
