SPECIFICATIONS
Current Rating:
Voltage Rating:
Contact Resistance:
Insulator Resistance:
Withstanding:
Insulator:
Contact:
Sleeve:
Processing Temp:
Operating Temp:
1.0A AC/DC
100V AC/DC
15m ohm. Max.
5000M ohm min.
1000V AC for one minute
PBT UL94V-0, Black
Beryllium Copper, Gold Plated
Copper Alloy, Tin Plated
235°C for 5 Sec
-40C to +105C
A
B
C
C
D
.3” Row Space
Circuits
06
08
14
16
18
20
24
28
A
7.62
10.16
17.78
20.32
22.86
25.40
30.48
35.56
B
5.08
7.62
15.24
17.78
20.32
22.86
27.94
33.02
C
10.16
10.16
10.16
10.16
10.16
10.16
10.16
10.16
Dimensions
D
Circuits
7.62
24
7.62
28
7.62
32
7.62
40
7.62
42
7.62
48
7.62
7.62
.6” Row Space
A
30.48
35.56
40.64
50.80
53.34
60.96
B
27.94
33.02
38.10
48.26
50.80
58.42
W/O middle bar (6~16P)
With middle bar (18-48P)
C
17.78
17.78
17.78
17.78
17.78
17.78
D
15.24
15.24
15.24
15.24
15.24
15.24
D
E
F
RoHS compliant
Rev.
Description
Date
Approved
Series
CMCX
Machine Contact
Socket
X=3,4,6 “ Row
Space
Positions
XX
3: 06, 08, 10, 14, 16, 18,
20, 22, 24, 28
4: 20, 22, 24, 28, 32
6: 24, 28, 32, 26, 40, 42,
48, 50, 52
Plating
XX
TN=Tin
SGXX=Selective
GDXX=Gold
XX=Flash if blank,
10,30u”
Frame
XXX
Blank=Std open
with bars
OPN=Open
CLD=Closed
E
F
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
06/01/07
06/01/07
06/01/07 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CMCX-XX-XX-XXX
