Technical Data Sheet
Solderless Power LED
30-01/X5C-AQSC
Features
. High Flux Output.
. Designed for High Current Operation.
. Low Thermal Resistance.
. Low Profile.
. Packaged in Tubes for Use with Automatic
Insertion Equipment.
. The product itself will remain within RoHS compliant version.
Descriptions
This revolutionary package design allows the light designer to reduce the number of LEDs
required and provide a more uniform and unique illuminated appearance than with other LED
solutions. This is possible through the efficient optical package design and high-current capabilities.
The low profile package can be easily coupled with reflectors or lenses to efficiently distribute
light and provide the desired light appearance.
Applications
. Automotive Lighting
. Electronic Signs and Signals
. Special Lighting application
Device Selection Guide
PART NO.
30-01/Y5C-AQSC
30-01/A5C-AQSC
30-01/R5C-AQSC
AlGaInP
Chip
Material
Emitted Color
Super Yellow
Super Sunset Orange
Lens Color
Water Clear
Hyper Red
Everlight Electronics Co., Ltd.
Device number:
http:\\www.everlight.com
Established date: 04-21-2006
Rev:1
Established by:
Page: 1 of 7
Max Chen
Technical Data Sheet
Solderless Power LED
30-01/X5C-AQSC
Package Dimensions
Notes:
1.All dimensions are in millimeters
2.An epoxy meniscus may extend about 1.5mm(0.059") down the leads
3.Tolerances unless dimensions
±0.25mm
Everlight Electronics Co., Ltd.
Device number:
http:\\www.everlight.com
Established date: 04-21-2006
Rev:1
Established by:
Page: 2 of 7
Max Chen
Technical Data Sheet
Solderless Power LED
30-01/X5C-AQSC
Absolute Maximum Ratings
Parameter
Continuous Forward Current
Peak Forward Current(Duty 1/10 @ 1KHZ)
Reverse Voltage
Operating Temperature
Storage Temperature
Soldering Temperature(T=5 sec)
LED Junction Temperature
Power Dissipation
Electrostatic Discharge
Symbol
I
F
I
FP
V
R
T
opr
T
stg
T
sol
T
j
P
d
ESD
Max
.
----
----
----
----
----
----
----
----
----
----
3.1
10
I
F
=20mA
nm
Rating
70
160
5
-40 ~ +100
-40 ~ +100
260 ± 5
115
220
2K
Units
mA
mA
V
℃
℃
℃
℃
mW
V
Electro-Optical Characteristics (Ta=25℃)
Parameter
Symbol
Part No.
30-01/Y5C-AQSC
Min.
3600
3600
3600
----
----
---
----
----
----
----
2.1
----
Typ.
4500
5100
4500
70
591
621
632
589
615
624
15
18
20
2.6
----
Condition
I
F
=70mA
I
F
=70mA
I
F
=70mA
I
F
=70mA
I
F
=20mA
Unit
mlm
mlm
mlm
deg
nm
Total Flux
Φv
2θ1/2
λp
30-01/A5C-AQSC
30-01/R5C- AQSC
Viewing Angle
Peak
Wavelength
30-01/X5C-AQSC
30-01/Y5C-AQSC
30-01/A5C-AQSC
30-01/R5C- AQSC
30-01/Y5C-AQSC
Dominant
Wavelength
λd
30-01/A5C-AQSC
30-01/R5C- AQSC
Spectrum
Radiation
Bandwidth
Forward
Voltage
Reverse
Current
30-01/Y5C-AQSC
△λ
30-01/A5C-AQSC
30-01/R5C- AQSC
I
F
=20mA
I
F
=70mA
V
R
=5V
nm
V
uA
V
F
I
R
30-01
/X5C-AQSC
30-01
/X5C-AQSC
Everlight Electronics Co., Ltd.
Device number:
http:\\www.everlight.com
Established date: 04-21-2006
Rev:1
Established by:
Page: 3 of 7
Max Chen
Technical Data Sheet
Solderless Power LED
30-01/X5C-AQSC
Rank
(1)
□
(2)
□
(3)
□
(1)
Vf(V)
Bin
3
4
5
6
7
Min
2.10
2.30
2.50
2.70
2.90
Max
2.30
2.50
2.70
2.90
3.10
(30-01/Y5C
) (2)
λd(nm)
Bin
Min
Max
1
2
586
590
590
594
(3)
Φv(mlm)
Bin
Q
R
S
Min
3600
4500
5650
Max
4500
5650
7150
3
594
598
(30-01/A5C
) (2)
λd(nm)
6
7
2
3
613.5
617
620
624
617
620
624
628
(30-01/R5C
) (2)
λd(nm)
*Measurement Uncertainty of Forward Voltage：±0.1V
*Measurement Uncertainty of Luminous Intensity:
±15%
Everlight Electronics Co., Ltd.
Device number:
http:\\www.everlight.com
Established date: 04-21-2006
Rev:1
Established by:
Page: 4 of 7
Max Chen
Technical Data Sheet
Solderless Power LED
30-01/X5C-AQSC
Typical Electro-Optical Characteristics Curves
Relative Intensity vs. Wavelength
1.0
0.8
0.6
0.4
0.2
0.0
540
% RED
% YELLOW
% AMBER
Forward Current vs. Forward Voltage
80
Forward Current(mA)
% YELLOW
% AMBER
% RED
Relative Intensity
60
40
20
560
580
600
620
640
660
680
1.8
1.9
WaveLength
2.0
2.1
2.2
2.3
Forward Voltage(Vf)
2.4
2.5
Relative Intensity vs. Forward Current
1.00
Forward Current vs. Ambient Temp.
80
70
MAXMUM DC CURRENT(mA)
0.80
RELATIVE INTENSITY
60
50
40
30
20
10
0
0
20
40
60
80
100 120 140
AMBIENT TEMPERATURE (C)
0.60
0.40
0.20
0.00
0
10
20
30
40
50
60
FORWARD CURRENT (mA)
70
RelativeIntensity vs. Angle Displacement
1.0
Relative intensity
0.8
0.6
0.4
0.2
0.0
90
60
0
30
-80
-60
-40
-20
0
View angle
ing
Everlight Electronics Co., Ltd.
Device number:
http:\\www.everlight.com
Established date: 04-21-2006
Rev:1
Established by:
Page: 5 of 7
Max Chen
