Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
500 STR/FLEX
LCDX500-56DF
Electro-Tin
500 STR/FLEX
Stranded Copper:
Class: G, H, I, K, M,
Locomotive
1-9/16 in.
5/16 in.
.50±.04
1.00±.02
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
PINK
P99
(L99)
1.48±.04
1.89±.04
Wire Strip Length
Stud Size
UL Listed Wire
Connector
PANDUIT
Wire inspection
window
.34±.02 DIA
(2) PLS
2.06±.04
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
Panduit Die Index No.
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
.26±.01
90°±5°
3.06
REF
PANDUIT
PINK DIE P99 (L99)
1.03±.01
CERTIFIED
Color coded
barrel markings
Beveled wire
entry
LISTED
Wire Connector
1.30±.01
3.56 REF
CORP.
01
REV
TINLEY PARK, ILLINOIS
3/08
DATE
LEM
BY
LEM
CHK
UPDATED TONGUE LENGTH
DESCRIPTION
ECN
LCDX500-56DF-6
Copper Lug - Two-Hole, Standard Flex Barrel, 90° Angle Tongue
