3-1437463-1: DescriptionOFF-DELAY RELAY, DPDT, MOMENTARY, 24VDC (COIL), 0.1-3s, SOCKET MOUNT; CategoryMechanical and electronic products relay; File Size109KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

3-1437463-1 Overview

OFF-DELAY RELAY, DPDT, MOMENTARY, 24VDC (COIL), 0.1-3s, SOCKET MOUNT

3-1437463-1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Objectid	1667239559
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	6.5
Maximum adjustable time delay	3 s
Minimum adjustable time delay	0.1 s
body width	50 mm
body height	83 mm
Body length or diameter	50 mm
Maximum coil voltage (AC)	24 V
Maximum coil voltage (DC)	24 V
Coil/Input Power Type	AC/DC
Contact (AC) maximum rated R load	5A@240VAC
Maximum contact current (AC)	5 A
Maximum contact voltage (AC)	240 V
Contact/Output Power Type	AC
Installation features	PANEL MOUNT
Maximum operating temperature	65 °C
Minimum operating temperature	-30 °C
physical size	50 X 50 X 83
Guideline	CE; CSA; UL
Relay action	MOMENTARY
Relay style	2 FORM C
Relay function	DPDT
Relay type	OFF-DELAY RELAY
surface mount	NO
Termination type	SOLDER/QUICK CONNECT

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

SCERX22EAA Product Details

Time Delay Relays

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

SCERX22EAA

(3-1437463-1)

T E I nternal N umber: 3 - 1 4 3 7 4 6 3 - 1

Product Highlights:

SC E Specification Grade True Off-Delay Timing Series

Input Voltage = 24 VAC

Input Voltage = 24 VDC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact Rating = 5A Resistive @ 120/240 VAC

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active
