3613T331K

Description
1 ELEMENT, 330uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT
CategoryPassive components    inductor
File Size98KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric Compare View All

3613T331K Overview

1 ELEMENT, 330uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT

3613T331K Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1646064427
package instruction1812
Reach Compliance Codeunknown
ECCN codeEAR99
uppercase and lowercase codes1812
DC Resistance14 Ω
Nominal inductance(L)330 µH
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial number3613
Number of functions1
Number of terminals2
Minimum quality factor (at nominal inductance)40
Maximum rated current0.085 A
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Tolerance10%
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Passive C omponents
>
Product Feature Selector
> Product Details
3613T331K Product Details
Live Product Chat
Inductors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3613T331K
(1624095-7)
T E I nternal N umber: 1 6 2 4 0 9 5 - 7
Product Highlights:
l
Inductor
l
Inductor Type = Molded Wirewound
l
Lead Type = Surface Mount Terminals
l
Wirewound
l
Inductance = 330 ?H
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
SMD C HIP INDUC TOR SERIES 3613T
(PDF, English)
Catalog Pages/Data Sheets:
l
Moulded C hip Inductor 18:12 - Type 3613C Series - Ty...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Inductor
l
Inductor Type = Molded Wirewound
l
Element
= Wirewound
l
Shielded
= No
Electrical Characteristics:
l
Inductance (?H)
= 330
l
DC Resistance (?)
= 14
l
C urrent, Maximum (mA)
= 85
l
Quality Factor
= 40
l
Package Type
= Taped and Reeled
l
Tolerance (%) = 10
Body Related Features:
l
Lead Type
= Surface Mount Terminals
l
Series
= 3613
l
Packaging Style
= 1812
l
Package, C omponent Size
= 4.5 x 3.2
l
Mount Style
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Operation/Application:
l
Application
= Standard
Other:
l
Brand = Sigma Inductors
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

3613T331K Related Products

3613T331K 1624095-7
Description 1 ELEMENT, 330uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT 1 ELEMENT, 330uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 1812, ROHS COMPLIANT
Is it Rohs certified? conform to conform to
Objectid 1646064427 1646063384
package instruction 1812 1812
Reach Compliance Code unknown unknown
ECCN code EAR99 EAR99
uppercase and lowercase codes 1812 1812
DC Resistance 14 Ω 14 Ω
Nominal inductance(L) 330 µH 330 µH
Inductor type GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR
Manufacturer's serial number 3613 3613
Number of functions 1 1
Number of terminals 2 2
Minimum quality factor (at nominal inductance) 40 40
Maximum rated current 0.085 A 0.085 A
Shape/Size Description RECTANGULAR PACKAGE RECTANGULAR PACKAGE
shield NO NO
surface mount YES YES
Terminal location DUAL ENDED DUAL ENDED
Terminal shape WRAPAROUND WRAPAROUND
Tolerance 10% 10%
