FSL110R4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> FSL110R4

FSL110R4: DescriptionPower Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3; CategoryDiscrete semiconductor The transistor; File Size84KB，8 Pages; ManufacturerInternational Rectifier （ Infineon ）; Websitehttp://www.irf.com/

Download Datasheet Parametric Compare View All

FSL110R4 Overview

Power Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3

FSL110R4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	International Rectifier （ Infineon ）
Parts packaging code	BCY
package instruction	CYLINDRICAL, O-MBCY-W3
Contacts	4
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	100 V
Maximum drain current (ID)	3.5 A
Maximum drain-source on-resistance	0.6 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-205AF
JESD-30 code	O-MBCY-W3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	235
Polarity/channel type	N-CHANNEL
Maximum pulsed drain current (IDM)	10.5 A
Certification status	Not Qualified
surface mount	NO
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	30
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

FSL110D, FSL110R

Data Sheet

December 2001

3.5A, 100V, 0.600 Ohm, Rad Hard, SEGR

Resistant, N-Channel Power MOSFETs

The Discrete Products Operation of Fairchild has developed

a series of Radiation Hardened MOSFETs speciﬁcally

designed for commercial and military space applications.

Enhanced Power MOSFET immunity to Single Event Effects

(SEE), Single Event Gate Rupture (SEGR) in particular, is

combined with 100K RADS of total dose hardness to provide

devices which are ideally suited to harsh space

environments. The dose rate and neutron tolerance

necessary for military applications have not been sacriﬁced.

The Fairchild portfolio of SEGR resistant radiation hardened

MOSFETs includes N-Channel and P-Channel devices in a

variety of voltage, current and on-resistance ratings.

Numerous packaging options are also available.

This MOSFET is an enhancement-mode silicon-gate power

ﬁeld-effect transistor of the vertical DMOS (VDMOS)

structure. It is specially designed and processed to be

radiation tolerant. The MOSFET is well suited for

applications exposed to radiation environments such as

switching regulation, switching converters, motor drives,

relay drivers and drivers for high-power bipolar switching

transistors requiring high speed and low gate drive power.

This type can be operated directly from integrated circuits.

Reliability screening is available as either commercial, TXV

equivalent of MIL-S-19500, or Space equivalent of

MIL-S-19500. Contact Fairchild for any desired deviations

from the data sheet.

Features

• 3.5A, 100V, r

DS(ON)

= 0.600

Ω

• Total Dose

- Meets Pre-RAD Speciﬁcations to 100K RAD (Si)

• Single Event

- Safe Operating Area Curve for Single Event Effects

- SEE Immunity for LET of 36MeV/mg/cm

with

up to 80% of Rated Breakdown and

of 10V Off-Bias

• Dose Rate

- Typically Survives 3E9 RAD (Si)/s at 80% BV

DSS

- Typically Survives 2E12 if Current Limited to I

• Photo Current

- 0.3nA Per-RAD(Si)/s Typically

• Neutron

- Maintain Pre-RAD Speciﬁcations

for 3E13 Neutrons/cm

- Usable to 3E14 Neutrons/cm

Symbol

Ordering Information

RAD LEVEL

10K

100K

SCREENING LEVEL

Commercial

TXV

Commercial

TXV

Space

PART NUMBER/BRAND

FSL110D1

FSL110D3

FSL110R1

FSL110R3

FSL110R4

Package

TO-205AF

Formerly available as type TA17616.

FSL110D, FSL110RH Rev. B

FSL110R4 Related Products

	FSL110R4	FSL110R3	FSL110D1
Description	Power Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3	Power Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3	Power Field-Effect Transistor, 3.5A I(D), 100V, 0.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-205AF, HERMETIC SEALED, METAL CAN-3
Is it lead-free?	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible
Parts packaging code	BCY	BCY	BCY
package instruction	CYLINDRICAL, O-MBCY-W3	CYLINDRICAL, O-MBCY-W3	CYLINDRICAL, O-MBCY-W3
Contacts	4	4	4
Reach Compliance Code	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99
Configuration	SINGLE WITH BUILT-IN DIODE	SINGLE WITH BUILT-IN DIODE	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	100 V	100 V	100 V
Maximum drain current (ID)	3.5 A	3.5 A	3.5 A
Maximum drain-source on-resistance	0.6 Ω	0.6 Ω	0.6 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR	METAL-OXIDE SEMICONDUCTOR	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-205AF	TO-205AF	TO-205AF
JESD-30 code	O-MBCY-W3	O-MBCY-W3	O-MBCY-W3
JESD-609 code	e0	e0	e0
Number of components	1	1	1
Number of terminals	3	3	3
Operating mode	ENHANCEMENT MODE	ENHANCEMENT MODE	ENHANCEMENT MODE
Maximum operating temperature	150 °C	150 °C	150 °C
Package body material	METAL	METAL	METAL
Package shape	ROUND	ROUND	ROUND
Package form	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL
Peak Reflow Temperature (Celsius)	235	235	235
Polarity/channel type	N-CHANNEL	N-CHANNEL	N-CHANNEL
Maximum pulsed drain current (IDM)	10.5 A	10.5 A	10.5 A
Certification status	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO
Terminal surface	TIN LEAD	TIN LEAD	TIN LEAD
Terminal form	WIRE	WIRE	WIRE
Terminal location	BOTTOM	BOTTOM	BOTTOM
Maximum time at peak reflow temperature	30	30	30
transistor applications	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON	SILICON
Maker	International Rectifier （ Infineon ）	-	International Rectifier （ Infineon ）
Base Number Matches	1	1	-
