Radial Leaded Inductors
SERIES 4669
-102M
-122M
-152M
-182M
-222M
-272M
-332M
-392M
-472M
-562M
-682M
-822M
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
-824K
-105K
-125K
-155K
-185K
-225K
-275K
-335K
-395K
-475K
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
40
40
40
40
40
40
40
40
40
35
35
35
35
50
50
50
50
50
50
50
40
40
50
55
50
70
70
70
70
70
70
70
70
70
65
60
50
70
75
80
80
80
80
70
65
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
7.90
2.50
2.50
2.50
2.50
2.50
2.50
2.50
2.50
2.50
2.50
2.50
2.50
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.010
0.012
0.015
0.020
0.025
0.028
0.036
0.050
0.055
0.090
0.110
0.115
0.120
0.140
0.155
0.180
0.230
0.265
0.345
0.370
0.500
0.685
0.885
1.200
1.495
1.725
1.955
2.070
2.185
2.530
3.335
3.450
5.290
5.405
5.930
6.325
7.130
10.00
14.26
15.76
17.60
19.32
21.75
26.00
29.90
3.60
3.30
3.00
2.55
2.30
2.15
1.90
1.60
1.55
1.40
1.10
1.05
1.04
0.95
0.91
0.85
0.75
0.70
0.61
0.59
0.51
0.44
0.38
0.33
0.29
0.27
0.25
0.24
0.23
0.22
0.20
0.19
0.16
0.15
0.14
0.14
0.13
0.11
0.10
0.09
0.08
0.08
0.07
0.07
0.06
7.00
6.00
5.00
4.80
4.40
4.00
3.70
3.40
3.20
2.80
2.60
2.20
2.10
2.00
1.60
1.50
1.40
1.30
1.20
1.10
1.00
0.95
0.90
0.85
0.80
0.65
0.60
0.55
0.50
0.45
0.41
0.39
0.35
0.32
0.29
0.27
0.25
0.21
0.19
0.17
0.15
0.14
0.13
0.12
0.11
Physical Parameters
Inches
Millimeters
A 0.374 to 0.400 9.50 to 10.16
B 0.165 Max.
4.19 Max.
C 0.310 Max.
7.87 Max.
D 0.750 Min.
19.05 Min.
E 0.020 Typical 0.50 Typical
F 0.300 Typical 7.62 Typical
G **0.400 Max.
10.16 Max.
** Clean Lead to Clean Lead
Mechanical Configuration
Radial leaded ferrite coil
Operating Temperature
–55°C to +125°C
Incremental Current
The DC Current at which the
inductance will be decreased by 5% maximum from
the zero DC value
Maximum Rated Current
Based on 40°C
temperature rise from 85°C ambient
Maximum Power Dissipation
0.200 watts at 85°C
Inductance Tolerance
Suffix letter listed in API Part
Number table: M = +/- 20%; K = +/- 10%
Packaging
Bulk only
*Complete part # must include series # PLUS the dash #
For further surface finish information,
refer to TECHNICAL section of this catalog.
