BZX84C3V6TR13TIN/LEAD datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> BZX84C3V6TR13TIN/LEAD

BZX84C3V6TR13TIN/LEAD: DescriptionZener Diode, 3.6V V(Z), 5.6%, 0.35W,; CategoryDiscrete semiconductor diode; File Size331KB，2 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

BZX84C3V6TR13TIN/LEAD Overview

Zener Diode, 3.6V V(Z), 5.6%, 0.35W,

BZX84C3V6TR13TIN/LEAD Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	90 Ω
Number of components	1
Maximum operating temperature	150 °C
Maximum power dissipation	0.35 W
Nominal reference voltage	3.6 V
surface mount	YES
Maximum voltage tolerance	5.6%
Working test current	5 mA
Base Number Matches	1

Preview

Download Datasheet

View All

BZX84C2V4

THRU

BZX84C47

SURFACE MOUNT

SILICON ZENER DIODE

350mW, 2.4 THRU 47 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR BZX84C2V4

Series are surface mount silicon Zener diodes. These

high quality voltage regulating diodes are designed

for use in industrial, commercial, entertainment and

computer applications.

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

350

-65 to +150

357

ELECTRICAL CHARACTERISTICS:

(TA=25°C), VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

BZX84C2V4

BZX84C2V7

BZX84C3V0

BZX84C3V3

BZX84C3V6

BZX84C3V9

BZX84C4V3

BZX84C4V7

BZX84C5V1

BZX84C5V6

BZX84C6V2

BZX84C6V8

BZX84C7V5

BZX84C8V2

BZX84C9V1

BZX84C10

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.4

7.0

7.7

8.5

9.4

NOM

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

MAX

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

TEST

CURRENT

IZT

5.0

MAXIMUM

ZENER

IMPEDENCE

ZZT @ IZT

100

ZZK @ IZK

600

500

480

400

150

100

150

1.0

MAXIMUM

REVERSE

CURRENT

IR @

μA

5.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

1.0

2.0

4.0

5.0

6.0

7.0

MAXIMUM

ZENER

VOLTAGE

TEMP.

CURRENT

COEFF.

IZM

ΘV

104

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

TYPE

MARKING

CODE

Tolerance Code

Tolerance

±1%

±2%

Part Number Identification

B Z X 84 C 4V 7

Nominal Value Code(i.e. 4.7 Volts)

Tolerance Code

Device Series

R7 (20-November 2009)
