AN15525A datasheet, PDF - EEWORLD Datasheet

AN15525A: DescriptionSilicon Monolithic Bipolar IC; CategoryOther integrated circuit (IC) Consumption circuit; File Size245KB，8 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html

Download Datasheet Parametric View All

AN15525A Overview

Silicon Monolithic Bipolar IC

Parameter Name	Attribute value
Maker	Panasonic
Parts packaging code	SFM
package instruction	,
Contacts	3
Reach Compliance Code	unknow
application	TV; MONITOR
Blanking output	NO
Commercial integrated circuit types	VERTICAL DEFLECTION IC
JESD-30 code	R-PSFM-T7
Number of functions	1
Number of terminals	7
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum supply voltage (Vsup)	30 V
Minimum supply voltage (Vsup)	12 V
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

DATA SHEET

Part No.

Package Code No.

AN15525A

T0220 - 7A

SEMICONDUCTOR COMPANY

MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD.

Publication date: January 2005

SDB00088AEB
