BI1-EH03-AP6X Overview

Inductive Sensor,

BI1-EH03-AP6X Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Sensor/Transducer Type	PROXIMITY SENSOR,INDUCTIVE
Base Number Matches	1

Preview

Download Datasheet

View All

Inductive sensor

BI1-EH03-AP6X

■

Smooth barrel, Ø 3 mm

■

Stainless steel, 1.4301

■

DC 3-wire, 10…30 VDC

■

NO contact, PNP output

■

Cable connection

Wiring Diagram

Type designation

Ident-No.

Ident-No (TUSA)

Rated switching distance Sn

Mounting conditions

Secured operating distance

Correction factors

Repeat accuracy

Temperature drift

Hysteresis

Ambient temperature

Operating voltage

Residual ripple

DC rated operational current

No-load current I

0

Residual current

Isolation test voltage

Short-circuit protection

Voltage drop at I

e

Wire breakage/Reverse polarity protection

Output function

Switching frequency

Design

Dimensions

Housing material

Active area material

Electrical connection

Cable quality

Cable cross section

Vibration resistance

Shock resistance

Protection class

MTTF

Switching state

Edition • 2017-09-15T05:06:46+02:00

BI1-EH03-AP6X

1619325

M1619325

Functional principle

Inductive sensors detect metal objects con-

tactless and wear-free. For this, they use a

high-frequency electromagnetic AC field that

1 mm

interacts with the target. Inductive sensors

Flush

generate this field via an RLC circuit with a

ð

(0,81 x Sn) mm

St37 = 1; Al = 0.5; Cu=0.45; stainless steel = 0.8; Ms

ferrite coil.

= 0.6

ð

2 % of full scale

ð

± 10 %

3…15 %

-25…+70 °C

10…30 VDC

ð

20 % U

ss

ð

100 mA

ð

10 mA

ð

0.1 mA

ð

0.5 kV

yes/ Cyclic

ð

2V

yes/ Complete

3-wire, NO contact, PNP

3 kHz

Smooth barrel, 3 mm

22 mm

Metal, V2A (1.4301)

Plastic, Polyester

Cable

2.6mm, LifY-11Y, PUR, 2

3 x 0.055 mm

55 Hz (1 mm)

30 g (11 ms)

IP67

2283 years acc. to SN 29500 (Ed. 99) 40 °C

2

LED yellow

1/3

TURCK Inc.

ñ

3000 Campus Drive Minneapolis, MN 55441-2656

ñ

Phone: 763-553-7300

ñ

Application Support: 1-800-544-7769

ñ

Fax 763-553-0708

ñ

www.turck.com
