IRKH430-18

Description
SUPER MAGN-A-pak-TM Power Modules
CategoryAnalog mixed-signal IC    Trigger device
File Size96KB,8 Pages
ManufacturerInternational Rectifier ( Infineon )
Websitehttp://www.irf.com/
Download Datasheet Parametric Compare View All

IRKH430-18 Overview

SUPER MAGN-A-pak-TM Power Modules

IRKH430-18 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
package instructionFLANGE MOUNT, R-PUFM-D3
Contacts5
Reach Compliance Codeunknow
Nominal circuit commutation break time200 µs
ConfigurationSINGLE WITH BUILT-IN FREE-WHEELING DIODE
Critical rise rate of minimum off-state voltage1000 V/us
Maximum DC gate trigger current200 mA
Maximum DC gate trigger voltage3 V
Quick connection descriptionG-GR
Description of screw terminalsA-K-AK
Maximum holding current500 mA
JESD-30 codeR-PUFM-D3
JESD-609 codee0
Maximum leakage current100 mA
On-state non-repetitive peak current16000 A
Number of components1
Number of terminals3
Maximum on-state current430000 A
Maximum operating temperature130 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)225
Certification statusNot Qualified
Maximum rms on-state current675 A
Maximum repetitive peak off-state leakage current100000 µA
Off-state repetitive peak voltage1800 V
Repeated peak reverse voltage1800 V
surface mountNO
Terminal surfaceTIN LEAD
Terminal formSOLDER LUG
Terminal locationUPPER
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeSCR
Base Number Matches1
Bulletin I27400 rev. A 09/97
IRK.430.. SERIES
THYRISTOR / DIODE and
THYRISTOR / THYRISTOR
Features
High current capability
3000 V
RMS
isolating voltage with non-toxic substrate
High surge capability
High voltage ratings up to 2000V
Industrial standard package
UL recognition pending
SUPER MAGN-A-pak
TM
Power Modules
430 A
Typical Applications
Motor starters
DC motor controls - AC motor controls
Uninterruptable power supplies
Wind mill
Major Ratings and Characteristics
Parameters
I
T(AV)
or I
F(AV)
@ T
C
I
T(RMS)
@ T
C
I
TSM
or I
FSM
@ 50Hz
@ 60Hz
I
2
t
@ 50Hz
@ 60Hz
I
2
√t
V
DRM
/V
RRM
range
T
STG
T
J
range
range
IRK.430..
430
82
675
82
15.7
16.4
1232
1125
12320
1600 to 2000
- 40 to 150
- 40 to 130
Units
A
°C
A
°C
KA
KA
KA
2
s
KA
2
s
KA
2
√s
V
°C
°C
www.irf.com
1
