5-1761208-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 5-1761208-1

5-1761208-1: DescriptionCONNECTOR, 4 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, RECEPTACLE, ROHS COMPLIANT; CategoryThe connector The connector; File Size116KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5-1761208-1 Overview

CONNECTOR, 4 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, RECEPTACLE, ROHS COMPLIANT

5-1761208-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Other features	POLARIZED, SHIELDED, SIDE ENTRY
Body/casing type	RECEPTACLE
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (50) OVER NICKEL
Contact completed and terminated	GOLD (50) OVER NICKEL
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYESTER
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	1761208
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD AND PANEL
Options	GENERAL PURPOSE
Shell surface	TIN
Shell material	BRASS
Total number of contacts	4
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Shielded Data Link (SDL)

Product Feature Selector

> Product Details

5-1761208-1 Product Details

Live Product Chat

Product View

SDL (Shielded Data Link)

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5-1761208-1

T E I nternal N umber: 5 - 1 7 6 1 2 0 8 - 1

Product Highlights:

C onnector

Receptacle

Receptacle C onfiguration = Standard

Number of C onductors = 4

Keying = E

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

C onnector, SDL

(PDF, English)

Application Specifications:

SDL Top-Entry and Side-Entry Printed C ircuit (PC ) Bo...

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

Gender

= Receptacle

Receptacle C onfiguration

= Standard

Number of C onductors

= 4

Grounding Options

= PC B and Panel Ground

PC B Retention Feature

= Yes

Shield Material = Brass

C omment = Prefix no. designates key configuration. Suffix no. is a

code for the number of conductors. Prefix & suffix nos. of plug

assemblies must match those of the intended mating receptacle.

Keys are molded in as an integral part of the plug & receptacle.

Mechanical Attachment:

Keying

= E

Body Related Features:

PC B Retention Method

= Mounting Holes

Shield Plating = Tin over C opper

Contact Related Features:

C ontact Base Material = Phosphor Bronze

C ontact Mating Area Plating Material = Gold (50)

Housing Related Features:

Housing Entry Style

= Top over Side

Housing Material

= Polyester

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Other:

Brand = AMP

Additional Information:
