05187
EMIF01-100
thru
Only One Name Means ProTek’Tion™
EMIF01-150
EMI FIL
TER/TVS ARRA
Y
APPLICA
TIONS
✔
Cellular Phones
✔
SMART Cards
✔
Notebooks
✔
Personal Digital Assistant (PDA)
✔
Ground Positioning System (GPS)
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
FEA
TURES
✔
ESD Protection > 25 kilovolts
✔
18 Watts Peak Pulse Power per Line (tp = 8/20µs)
✔
Bidirectional EMI Filtering/TVS Low Pass Filters
✔
Low Insertion Loss: -3db Roll-Off @ 200MHz
✔
Protects Up to Two (2) Data Lines
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SC-70-5L
✔
Weight 0.1 grams (Approximate)
✔
Flammability rating UL 94V-0
✔
8mm Tape and Reel Per EIA Standard 481
✔
Marking: Marking Code & Pin One Defined By Dot on Top of Package
SC-70-5L
PIN CONFIGURA
TION
IN 1
1
2
3
5
OUT 1
GND
IN 2
4
OUT 2
05187.R0 8/03
1
www.protekdevices.com
EMIF01-100
thru
EMIF01-150
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
Typical Series Resistance per Line
SYMBOL
P
PP
T
J
T
STG
R
VALUE
18
-55°C to 150°C
-55°C to 150°C
100 to 150
UNITS
Watts
°C
°C
Ohms
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
REVERSE
LEAKAGE
CURRENT
@ V
WM
I
D
µA
0.5
0.5
TYPICAL
FORWARD
VOLTAGE
CUT-OFF
MAXIMUM
FREQUENCY CAPACITANCE
(See Note 1)
V
WM
VOLTS
EMIF01-100
EMIF01-150
E10
E15
3.0
3.0
@ 1mA
V
(BR)
VOLTS
6.0
6.0
I@50mA, 8/
20µs
V
F
VOLTS
1.0
1.0
MHz
220
200
@ 0V, 1 MHz
C
pF
26
26
Note 1:
Cin between pins 1 & 2, 3 & 2, 4 & 2 and 5 & 2.
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
1,000
I
PP
- Peak Pulse Current - % of I
PP
P
PP
- Peak Pulse Current - Watts
120
100
80
60
40
20
0
t
f
FIGURE 2
PULSE WAVE FORM
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
100
e
-t
18W, 8/20µs Waveform
10
t
d
= t I /2
PP
0
0.01
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
0
5
10
15
20
t - Time - µs
25
30
05187.R0 8/03
2
www.protekdevices.com
EMIF01-100
thru
EMIF01-150
GRAPHS
FIGURE 3
INSERTION LOSS - EMIF01-100
0
-5
-10
Gain (dB)
-15
-20
-25
-30
-35
1
10
100
Frequency (MHz)
1000
10000
0
-5
-10
Gain (dB)
FIGURE 4
INSERTION LOSS - EMIF01-150
-15
-20
-25
-30
-35
1
10
100
Frequency (MHz)
1000
10000
FIGURE 5
OVERSHOOT & CLAMPING VOLTAGE FOR EMIF01-100
40
5 Volts per Division
30
20
10
0
ESD Test Pulse: 25 kilovolt, 1/30ns (waveform)
05187.R0 8/03
3
www.protekdevices.com
EMIF01-100
thru
EMIF01-150
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
SC -70-5L
D
E
5
4
K
J
0º - 8º
PACKAGE DIMENSIONS
DIM
MILLIMETERS
MIN
MAX
1.90
1.15
0.80
0.15
0.65 BSC
1.30 BSC
0.80
0.08
1.90
0
0.26
2.15
1.35
1.00
0.30
-
-
1.10
0.25
2.15
0.10
0.46
INCHES
MIN
0.074
0.045
0.031
0.006
0.0255 BSC
0.0512 BSC
0.031
0.003
0.074
0
0.010
MAX
0.084
0.055
0.040
0.012
-
-
0.043
0.010
0.084
0.004
0.018
1
2
3
L
J
B
M
V
F
A
G
A
B
C
D
E
F
G
J
K
L
M
C
MOUNTING PAD
4
TYPICAL
DIM Millimeters
1
2
3
4
5
6
7
0.50
1.30
0.65
2.40
0.60
0.70
2.50
Inches
0.020
0.051
0.026
0.094
0.024
0.028
0.098
3
2
1
5
6
7
NOTES
1. Dimensioning and tolerances per ANSI Y14.5M, 1985.
2. Controlling Dimension: Inches
3. Dimensions are exclusive of mold flash and metal burrs.
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 3,000 pieces per 8mm tape,
i.e.,
EMIF01-100-T7.
Outline & Dimensions: Rev 0 - 11/01, 06005
COPYRIGHT © ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics
described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the
final judgement concerning selection and specifications is the buyer’s and that in furnishing engineering
and technical assistance, ProTek assumes no responsibility with respect to the selection or
specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail:
sales@protekdevices.com
Web Site:
www.protekdevices.com
05187.R0 8/03
4
www.protekdevices.com
