Bussmann
®
Fast-Acting Glass Fuses
For ⁄Ω¢∑ ≈ 1∑ (6.3mm ≈ 25.4mm)
Dimensional Data
.266
"
1.500
"
(REF)
AGX
AGX-V
General Information:
• Glass. Formerly designated
8AG.
• Types MJB and MJW now called AGX.
• For instruments, electronic, and small appliance circuits.
• Mounts in Buss panel mounted fuseholders types HJM, HMS,
and HJL; In-line holders types HHB, HFB, and HRK; and Buss
fuseblocks 4520 and 3808 series and
⁄Ω¢∑
clips.
Time-Current Characteristic Curves–Average Melt
(Full Size Curves Available)
⁄Ω¢
1
2
100
5
AMPERE
RATING
1"
(±0.031)
1.042"
(±0.031)
.25"
(±0.003)
1.500
"
(REF)
TIME IN SECONDS
U.L.
Recog.
Catalog Symbol:
AGX
⁄Ω¢∑ ≈ 1∑ (6.3mm ≈ 25.4mm) 8AG
Fast-Acting
Agency Approvals:
Std. 248-14
0-5A U.L. Listed, Guide JDYX, File E19180
5.1-20A U.L. Recognized, Guide JDYX2, File E19180
CSA Certified, C22.2 No. 248.14, Class 1422-01, File 53787
Body Material:
Glass
Ferrule Material:
Brass
Ferrule Plating:
Nickel
Packaging & Ordering Information:
AGX
Package Code
Blank
5 in
BK/
100 in
Product
Symbol
0–15 AMP: 0.32
"
(REF)
20–30 AMP: 0.40
"
10
1
–
V
–
(See Table)
Rated Current
Lead
Blank -no lead
V-Axial lead
Electrical Ratings (Catalog Symbol and Amperes)
250 Volts AC
AGX-⁄Ω∞ºº
AGX-⁄Ω™ºº
AGX-⁄Ω¡ºº
AGX-⁄Ω£™
AGX-⁄Ω¡§
AGX-⁄Ω¡º
AGX-⁄Ω•
AGX-¤Ω¡º
AGX-‹Ω¡§
U.L.
Listed
& CSA
.1
250 Volts AC
AGX-⁄Ω¢
AGX-‹Ω¡º
AGX-‹Ω•
AGX-›Ω¡º
AGX-⁄Ω™
AGX-‹Ω¢
AGX-1
AGX-1⁄Ω¢
AGX-1⁄Ω™
U.L.
Listed
& CSA
250 Volts AC
AGX-2
AGX-2⁄Ω™
AGX-3
AGX-4
AGX-5
AGX-6
AGX-7
—
U.L.
Listed
U.L. Listed
& CSA
32 Volts AC
AGX-8
AGX-10
AGX-15
AGX-20
AGX-25
AGX-30
—
—
—
125 Volts AC
.1
10
1
RMS SYMMETRICAL CURRENT IN AMPERES
Test Specifications
Fuse
Load Opening Time
110% 4 Hours (min.)
135% 1 Hour (max.)
200% 5 Seconds (max.)
Carton Quantity and Weight
Ampere
Ratings
⁄Ω∞ºº-30
*Weight per carton.
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 Vac, 75-1500 Vdc). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 314-527-1270 for more information.
Carton
Qty.
100
Weight*
Lbs.
0.76
Kg.
345
AGX
(⁄Ω
짧 to 30A)
AGX
(⁄Ω
짧
to 2A)
The only controlled copy of this BIF document is the electronic read-only version located on the
Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This
bulletin is intended to clearly present comprehensive product data and provide technical infor-
mation that will help the end user with design applications. Bussmann reserves the right, without
notice, to change design or construction of any products and to discontinue or limit distribution
of any products. Bussmann also reserves the right to change or update, without notice, any
technical information contained in this bulletin. Once a product has been selected, it should be
tested by the user in all possible applications.
12-23-98
SB98107
Rev. A
Form No. AGX
Page 1 of 1
BIF Doc #2041
