1BC-4E-103E: DescriptionPower/Signal Relay, SPDT, Momentary, 0.045A (Coil), 2.2VDC (Coil), 25mW (Coil), 2A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Panel Mount,; CategoryMechanical and electronic products relay; File Size225KB，2 Pages; ManufacturerHi-G Relays

Download Datasheet Parametric View All

1BC-4E-103E Overview

Power/Signal Relay, SPDT, Momentary, 0.045A (Coil), 2.2VDC (Coil), 25mW (Coil), 2A (Contact), 28VDC (Contact), DC Input, AC/DC Output, Panel Mount,

1BC-4E-103E Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
body width	10.41 mm
body height	32.54 mm
Body length or diameter	20.57 mm
Maximum coil current (DC)	0.045 A
Coil power	25 mW
Coil resistance	48.89 Ω
Maximum coil voltage (DC)	2.2 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	1A@115VAC
Maximum contact current (AC)	1 A
Maximum contact current (DC)	2 A
Contact (DC) maximum rated R load	2A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	100000 Cycle(s)
JESD-609 code	e4
Installation features	PANEL MOUNT
operating hours	18 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
physical size	20.57mm x 10.41mm x 32.54mm
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
release time	6 ms
seal	HERMETICALLY SEALED
surface mount	NO
Terminal surface	GOLD
Termination type	WIRE
Base Number Matches	1
