2900 Series
Shielded Surface Mount Inductors
SELECTION GUIDE
Order Code
29102C
29152C
29222C
29332C
29472C
29682C
29103C
29153C
29223C
29333C
29473C
29683C
29104C
29154C
29224C
29334C
29474C
29684C
29105C
Inductance (10kHz, 0.1V
AC
)
Nom.
Min. – Max.
μH
μH
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
0.70 – 1.30
1.05 – 1.95
1.54 – 2.86
2.31 – 4.29
3.29 – 6.11
4.76 – 8.84
8.0 – 12.0
12.0 – 18.0
17.6 – 26.4
26.4 – 39.6
37.6 – 56.4
54.4 – 81.6
80.0 – 120
120 – 180
176 – 264
264 – 396
376 – 564
544 – 816
800 – 1200
Idc
2
Max.
A
6.0
5.5
5.0
4.0
2.3
2.1
1.8
1.5
1.2
1.0
850mA
650mA
530mA
470mA
380mA
320mA
260mA
210mA
180mA
Rdc
Max.
mΩ
16
18
20
28
30
40
45
65
85
120
170
250
360
500
760
1000
1600
2400
4100
FEATURES
RoHS compliant
Low profile
Surface mount
Inductance range from 1.0μH to 1.0mH
Tape & reel
UL 94V-0 materials
J-STD-020D.1 reflow
PRODUCT OVERVIEW
The 2900 series is a range of bobbin-wound,
shielded inductors. They are suitable for power-
line filtering found in consumer electronics such
as desktop computers, handheld devices and GPS
systems, as well as in a vast range of industrial
and telecom applications including network hubs,
bridges & routers, and high frequency wireless
communication devices.
These surface mount inductors are extremely
compact and have an integral shield, making them
useful in EMI sensitive applications.
For lower current ratings see also our lower
profile 2900L series.
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
Storage temperature range
-40°C to 85°C
-40°C to 125°C
SOLDERING INFORMATION
1
Peak reflow solder temperature
Pin finish
Moisture sensitivity level
3
250˚C
Tin
1
PACKAGE SPECIFICATIONS
Mechanical Dimensions
9.
2.1± 0.1
(0.083±0.004)
2.6 (0.102) Ref.
7.2 (0.283) Ref.
8
)
86
.3
(0 ef.
R
2.0 (0.079) Ref.
4.0 (0.157) Max.
Recommended Footprint Details*
7.2 (0.283) Max.
102C
7.2 (0.283) Max.
*Distance between the outside ends of the terminations is 6.6±1.5 (0.26±0.06)
Unless otherwise stated, all dimensions in mm (inches) ± 0.25 (0.010).
Package weight: 0.7g Typ.
For full details go to
www.murata-ps.com/rohs
1 For further information, please visit www.murata-ps.com/rohs
2 The maximum DC current is the value at which the inductance
falls to 75% of its nominal value or when its temperature rise
reaches 40°C, whichever is sooner.
3 When tested to moisture sensitivity level 1, as described per
IPC/JEDEC J-STD-020D, products passed electrical testing,
package coplanarity and visual inspection.
All specifications typical at T
A
=25°C
www.murata-ps.com/support
KMP_2900C_C01
Page 1 of 3
2900 Series
Shielded Surface Mount Inductors
PACKAGE SPECIFICATIONS
Reel Dimensions
Ø330.5 (13.012) Max.
50 (1.97) Min.
13.50 0.531
Ø
12.80 0.504
Leader Section
400 (15.748) Min.
100 (3.937)
Min.
15.9-19.4*
(0.626-0.764)
Ø
1.50 (0.059) Min.
22.4
(0.882)
Max.
†
Goods
Enclosure
Section
16.4-16.6
(0.646-0.654)
†
Trailer Section
160 (6.299) Min.
All dimension in mm [inches]
* Includes flange distortion at outer edge
† Measured at hub
Ø20.20 (Ø0.795) Min.
Tape Outline Dimensions
4.00
(0.157)
1.75 (0.069)
2.00 (0.079)
Ø1.50 +0.10 (Ø0.059 +0.004 )
-0.00
-0.00
7.50 (0.295)
16.0 +0.3 (0.63 +0.012 )
-0.004
-0.1
102C
0.60 (0.024)
0.35 (0.014)
4.00 (0.157)
Reel Quantity: 1000
Unless otherwise stated all dimensions in mm (inches) ±0.1 (0.004)
12.00 (0.472)
Direction of unreeling
