HCPL-814-060E datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> HCPL-814-060E

HCPL-814-060E: DescriptionAC Input Phototransistor Optocoupler High Density Mounting Type; CategoryLED optoelectronic/LED photoelectric; File Size83KB，6 Pages; ManufacturerHP（Keysight）; Websitehttp://www.semiconductor.agilent.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

HCPL-814-060E Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HCPL-814-060E	-	-	View	Buy Now

HCPL-814-060E Overview

AC Input Phototransistor Optocoupler High Density Mounting Type

HCPL-814-060E Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	HP（Keysight）
package instruction	LEAD FREE, DIP-4
Reach Compliance Code	unknown
Is Samacsys	N
Other features	UL RECOGNIZED, VDE APPROVED
Coll-Emtr Bkdn Voltage-Min	35 V
Configuration	SINGLE
Current transmission ratio - minimum value	20%
Nominal current transfer ratio	20%
Maximum dark power	100 nA
Maximum forward current	0.05 A
Maximum forward voltage	1.4 V
Maximum insulation voltage	5000 V
Installation features	THROUGH HOLE MOUNT
Number of components	1
Maximum on-state current	0.05 A
Maximum operating temperature	100 °C
Minimum operating temperature	-30 °C
Optoelectronic device types	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Maximum power dissipation	0.15 W
Maximum response time	0.000018 s
surface mount	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Agilent HCPL-814

AC Input Phototransistor

Optocoupler

High Density Mounting Type

Data Sheet

Features

• AC input response

• High input-output isolation voltage

iso

= 5,000 V

rms

)

• Low collector dark current

CEO

: max. 10

-7

A at V

= 20 V)

• Current transfer ratio

(CTR: min. 20% at I

1 mA,

= 5 V)

• Response time

: typ. 4

µs

at V

= 2 V, I

= 2 mA,

= 100

Ω)

• Compact dual-in-line package

• UL approved

• CSA approved

• IEC/EN/DIN EN 60747-5-2

approved

• Options available:

– Leads with 0.4" (10.16 mm)

spacing (W00)

– Leads bend for surface

mounting (300)

– Tape and reel for SMD (500)

– IEC/EN/DIN EN 60747-5-2

approvals (060)

Applications

• Detecting or monitoring AC signals

• AC line/digital logic isolation

• Programmable logic controllers

• AC/DC – input modules

Description

The HCPL-814 contains a

phototransistor, optically coupled

to two light emitting diodes

connected inverse parallel. It can

operate directly by AC input

current. It is packaged in a 4-pin

DIP package and available in wide-

lead spacing option and lead bend

SMD option. Input-output isolation

voltage is 5000 V

rms

. Response

time, t

, is typically 4

µs

and

minimum CTR is 20% at input

current of

1 mA.

Ordering Information

Specify Part Number followed by

Option Number (if desired).

HCPL-814-XXXE

Lead Free

Option Number

000 = No Options

060 = IEC/EN/DIN EN 60747-5-2

Option

W00 = 0.4" Lead Spacing Option

300 = Lead Bend SMD Option

500 = Tape and Reel Packaging

Option

00A = Rank Mark A

Functional Diagram

1. ANODE, CATHODE

2. CATHODE, ANODE

3. EMITTER

4. COLLECTOR

CAUTION:

It is advised that normal static precautions be taken in handling and assembly of this component to

prevent damage and/or degradation which may be induced by ESD.

HCPL-814-060E Related Products

	HCPL-814-060E	HCPL-814	HCPL-814-000E	HCPL-814-00AE	HCPL-814-300E	HCPL-814-W00E	HCPL-814-500E
Description	AC Input Phototransistor Optocoupler High Density Mounting Type	AC Input Phototransistor Optocoupler High Density Mounting Type	AC Input Phototransistor Optocoupler High Density Mounting Type	AC Input Phototransistor Optocoupler High Density Mounting Type	1 CHANNEL AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC Input Phototransistor Optocoupler High Density Mounting Type	AC Input Phototransistor Optocoupler High Density Mounting Type
Is it Rohs certified?	conform to	incompatible	conform to	conform to	conform to	conform to	conform to
Maker	HP（Keysight）	HP（Keysight）	HP（Keysight）	HP（Keysight）	HP（Keysight）	HP（Keysight）	HP（Keysight）
package instruction	LEAD FREE, DIP-4	DIP-4	LEAD FREE, DIP-4	LEAD FREE, DIP-4	LEAD FREE, SMD, 4 PIN	DIP-4	LEAD FREE, SMD, 4 PIN
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Other features	UL RECOGNIZED, VDE APPROVED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED
Coll-Emtr Bkdn Voltage-Min	35 V	35 V	35 V	35 V	35 V	35 V	35 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Nominal current transfer ratio	20%	20%	20%	50%	20%	20%	20%
Maximum dark power	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA	100 nA
Maximum forward current	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A
Maximum insulation voltage	5000 V	5000 V	5000 V	5000 V	5000 V	5000 V	5000 V
Number of components	1	1	1	1	1	1	1
Maximum operating temperature	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C	100 °C
Minimum operating temperature	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C	-30 °C
Optoelectronic device types	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER	AC INPUT-TRANSISTOR OUTPUT OPTOCOUPLER
Is Samacsys	N	-	N	N	N	N	N
Current transmission ratio - minimum value	20%	-	20%	50%	20%	20%	20%
Maximum forward voltage	1.4 V	-	1.4 V	1.4 V	1.4 V	1.4 V	1.4 V
Installation features	THROUGH HOLE MOUNT	-	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	SURFACE MOUNT	THROUGH HOLE MOUNT	SURFACE MOUNT
Maximum on-state current	0.05 A	-	0.05 A	0.05 A	0.05 A	0.05 A	0.05 A
Maximum power dissipation	0.15 W	-	0.15 W	0.15 W	0.15 W	0.15 W	0.15 W
Maximum response time	0.000018 s	-	0.000018 s	0.000018 s	0.000018 s	0.000018 s	0.000018 s
surface mount	NO	-	NO	NO	YES	NO	YES
Base Number Matches	1	-	1	1	1	1	1
