REVISION
REV.
A
DESCRIPTION
RoHS Compliancy
DATE
06-01-06
APPROVED
DP
THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR OR
COMMUNICATED TO A THIRD PARTY WITHOUT THE
EXPRESS WRITTEN PERMISSION OF AN OFFICER OF
QUALTEK ELECTRONICS.
NOTES:
1.
2.
3.
4.
5.
6.
∅76.2
71.37
MATERIAL: C1008 BRIGHT BASIC WIRE
FINISH: BRIGHT NICKEL CHROME PLATING
0.35 ± 0.05 DEPTH OF SERRATIONS ON WIRE
RING:
∅1.6
± 0.1mm
RIB:
∅1.8
± 0.1mm
GENERAL TOLERANCE UNLESS NOTED IS ± 0.5mm
RoHS COMPLIANT
∅4.57
± 0.2
4.57REF
ID.∅14.2
4.95REF
Dim
range
(mm)
0-5
5-16
16-64
64-250
250-1000
1000-1500
Tolerance
+/-
(mm)
0.1
0.15
0.2
0.4
0.5
1.0
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
FAN-S DIVISION
08132
WIRE FORM FAN GUARD (80mm)
UNIT: mm
REV: A
Approved / Date
JJH / 12-06-04
Drawn / Date
B. ZHANG
12-06-04
Checked / Date
12-06-04
