Datasheet for 76650-0227
General Information
Part Number:
76650-0227
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Mini-Latch Deluxe Connector Kit
Friction Lock Vertical and Right Angle Header and Receptacle
Mini-Latch™
(Molex parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current:
Voltage:
Wire size:
Product Highlights
Mini-Latch connectors provide a reliable interface for industry-standard 2.50mm
(.098" ) wire-to-board applications. The system includes a box-style contact
design and housing-side terminal latch to provide protection to the contact area
during and after assembly. The durable housing also includes guide rails and
molded tabs to facilitate mating and unmating.
Features and Benefits
• Friction lock provides good mating
retention
• Box-style contact protects contact area
• Polarizing features ensures proper
mating
• Guide rails and molded ledges
facilitates mating and unmating
Applications
• Datacommunication equipment
• Printers and faxes
• PCs and monitors
• Automotive
Wire-to-Board
2.50mm (.098")
Receptacle and Header
Vertical and Right Angle
Includes 3, 4 and 6 Circuits
(1.5 - 3) Amps depending on AWG
250 Volts
28-22 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0227
Bill of Materials for Part No. 76650-0227
Country
Molex Part No. of Origin
50802-9101
51191-0300
51191-0400
51191-0600
22-04-1031
22-04-1041
22-04-1061
22-05-1032
22-05-1042
22-05-1062
Japan
Japan
Japan
Japan
China
China
China
Ireland
Ireland
Ireland
Description
Mini-Latch™ Female Crimp Terminals 28-22 AWG
2.50mm (.098") Pitch Mini-Latch™ Receptacles 3 Circuits
2.50mm (.098") Pitch Mini-Latch™ Receptacles 4 Circuits
2.50mm (.098") Pitch Mini-Latch™ Receptacles 6 Circuits
2.50mm (.098") Pitch Vertical Headers 3 Circuits
2.50mm (.098") Pitch Vertical Headers 4 Circuits
2.50mm (.098") Pitch Vertical Headers 6 Circuits
2.50mm (.098") Pitch Right Angle Headers 3 Circuits
2.50mm (.098") Pitch Right Angle Headers 4 Circuits
2.50mm (.098") Pitch Right Angle Headers 6 Circuits
Quantity in
Kit
130
10
10
10
5
5
5
5
5
5
Recommended Molex Tool(s) for Part No. 76650-0227*
Country
Molex Part No. of Origin
63811-5200 *
*Tool(s) not included in kit. Tool(s) ordered separately.
Description
Germany
Hand Crimp Tool for 2.50mm (.098")
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
