KRA524T: DescriptionEPITAXIAL PLANAR PNP TRANSISTOR (HIGH CURRENT SWITCHING, INTERFACE CIRCUIT AND DRIVER CIRCUIT); CategoryDiscrete semiconductor The transistor; File Size67KB，5 Pages; ManufacturerKEC; Websitehttp://www.keccorp.com/

Download Datasheet Parametric Compare View All

KRA524T Overview

EPITAXIAL PLANAR PNP TRANSISTOR (HIGH CURRENT SWITCHING, INTERFACE CIRCUIT AND DRIVER CIRCUIT)

KRA524T Parametric

Parameter Name	Attribute value
Maker	KEC
package instruction	SMALL OUTLINE, R-PDSO-G5
Contacts	5
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	BUILT-IN BIAS RESISTOR RATIO IS 1
Maximum collector current (IC)	0.8 A
Collector-emitter maximum voltage	50 V
Configuration	COMMON EMITTER, 2 ELEMENTS WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)	56
JESD-30 code	R-PDSO-G5
Number of components	2
Number of terminals	5
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	200 MHz

Preview

Download Datasheet

View All

SEMICONDUCTOR

TECHNICAL DATA

HIGH CURRENT SWITCHING APPLICATION.

INTERFACE CIRCUIT AND DRIVER CIRCUIT APPPLICATION.

FEATURES

With Built-in Bias Resistors.

Simplify Circuit Design.

Reduce a Quantity of Parts and Manufacturing Process.

High Output Current : -800mA.

KRA521T~KRA526T

EPITAXIAL PLANAR PNP TRANSISTOR

DIM MILLIMETERS

2.9 + 0.2

1.6+0.2/-0.1

0.70 + 0.05

0.4 + 0.1

2.8+0.2/-0.3

1.9 + 0.2

0.95

0.16 + 0.05

0.00-0.10

0.25+0.25/-0.15

0.60

0.55

EQUIVALENT CIRCUIT

OUT

TYPE NO.

KRA521T

KRA522T

KRA523T

KRA524T

R1 (k )

2.2

4.7

2.2

R2 (k

2.2

4.7

)

1. Q

IN (BASE)

2. Q

, Q

COMMON (EMITTER)

3. Q

IN (BASE)

4. Q

OUT (COLLECTOR)

5. Q

OUT (COLLECTOR)

COMMON(+)

KRA525T

KRA526T

TSV

EQUIVALENT CIRCUIT (TOP VIEW)

MAXIMUM RATING (Ta=25

Output Voltage

)

SYMBOL

KRA521T~526T

KRA521T

KRA522T

KRA523T

KRA524T

KRA525T

KRA526T

CHARACTERISTIC

RATING

-50

-10, 10

-12, 10

-20, 10

-30, 10

-10, 5

-12, 6

Input Voltage

Output Current

Power Dissipation

Junction Temperature

Storage Temperature Range

* Package mounted on a ceramic board (600

0.8

)

KRA521T~526T

stg

-800

0.9

150

-55 150

Marking

MARK SPEC

TYPE

MARK

KRA521T

KRA522T

KRA523T

KRA524T

KRA525T

KRA526T

Type Name

2002. 7. 9

Revision No : 2

UNIT

Lot No.

1/5
